26
FM+ C
• Check that the VU meter is lit to see if there is a signal coming from your audio source. Check and correct
your audio source, if necessary.
• Check to see if the Headphone Volume Level hasn't been turned all the way down. If so, increase it.
• Check to see if there is an incorrect or defective connection from your audio source.
• Check and correct your audio gain level, if necessary.
Noise or Distortion in the Audio
• Check to see if there is noise in the audio source. To find out, disconnect the audio cable. If the noise
disappears your noise problem is in the source. Correct or repair your audio source.
• Ensure the Audio Source configuration is set to match the audio source input device. See "Audio Source
Connections" on page 7 for how to properly configure the Audio Source.
• Check for ground loops or noise on the input signal. If you are still having trouble, call your Authorized
Williams AV dealer or representative.
Noise in audio grows when program is silent
• The Audio Gain Control may be set too high. You may be seeing the +6 dB level indicator lighting all the
time on the front of the device. See "Audio Source (OLED or Web Page)" on page 12.
• Check the Compression Ratio, which may be inappropriate for the type of program being transmitted. Try
setting the Compression Ratio to 1:1 (compression off). See "Dynamic Range Compression" on page 13.
Volume too quiet
• The audio gain control may be set incorrectly on the transmitter. Correct the Audio Gain control setting by
adjusting it until the sound level peaks between 0 and 6 dB.
• Check the batteries in the receiver. For non-rechargeable (alkaline) batteries, they may need replaced. If you
are using rechargeable batteries, ensure the batteries are fully charged prior to use.
• The audio input may not be configured for the audio source being used. If not, correct the setting of the
Audio Source control menu. See "Audio Source Connections" on page 7.
• Some users may not be helped by this system. Severe hearing loss may require using the system with a
T-Coil and personal hearing aid rather than headphones.
• If using Wi-Fi, some phones and tablets have the ability to broadcast to a T-coil; research the phone model
to see if this is an option.
Wi-Fi reception difficulties
No Reception
• Ensure the listener's device is connected to the correct WaveCAST network, has the current iOS or Android
app installed, and is listening on the same channel as the FM+ C is transmitting on.
Missing Channel Image on App
• Images may not load when many users are connected. Try reloading the list of channels.
FM reception difficulties
NOTE: Be sure to listen to the audio transmission on the FM+ C headphone jack prior to checking the receiver
reception.
No Reception
• Ensure the listeners have the receiver on the same channel as the FM+ C is broadcasting on.
• Ensure the FM icon on the front panel is bright or the FM status at the top of the web page shows "On The
Air".
• If using an FM Receiver, ensure the Williams AV headphones are properly plugged in. The headphone cord
acts as an antenna for the receiver.
Insufficient range, good reception near transmitter, poor at a distance
• Ensure the transmitting antenna was correctly installed (see "Installing the ANT 025 Whip Antenna" on
page 6). If not, correct or replace the antenna. If a remote antenna was installed, check the cables and
connections. The signal should be clearly audible up to at least a 100-foot distance with the ANT 025.
• Ensure the transmitting antenna is not in an unsuitable location. Perhaps the transmitting antenna was
installed inside a metal enclosure or is separated from the reception area by electrically conducting objects.
(i.e., steel stud walls, heating ducts, substantial structural steel, or 2x2 or 2x4 ceiling grid.) In either case,
reinstall the antenna according to installation instructions, locating it outside metal enclosures and away
from electrically conducting objects.
• A strong interfering signal may exist. Ensure the transmitter and antenna are correctly installed. Set the
transmitter to FULL power output. If this does not solve the problem, try operating the transmitter on a
different channel/frequency.
