16
FM+ C
unable to stream. Unicast device will always be limited to 4 devices on the network, and therefore do not have a
Max Servers on Subnet setting. If unicast devices are included on the network, the Max Servers on Subnet setting
on multicast devices must be set to 4.
If only multicast devices are included, the maximum can be set to 4 or 8, as long as Max Servers on Subnet
settings is the same on all devices. If settings are mismatched, the server will be unable to stream audio and will
throw an Incompatible Server error. Devices that are missing this feature may need their firmware updated.
Adjusting Network Settings
The Network Settings screen where the IP Address Mode (Static or DHCP), the IP Address, and Subnet Mask are
set via the web page. See "Network Settings" on page 15 for details on how to use the web page.
Network Settings:
IP Address Mode Static or DHCP
IP Address If set to DHCP mode "Current IP Address" is displayed. When set to Static mode, these fields appear
as "Static IP Address", "Static Subnet Mask", and "Static Gateway Address". When the "IP Address Mode" is set to
Static, the IP information must be manually entered.
Subnet Mask If the IP Address Mode is set to Static, this is where the Subnet Mask is manually entered
Gateway If the IP Address Mode is set to Static, this is where the gateway is manually entered
Note: Subnet Mask and Gateway only apply when Static is selected
Mac Address this is displayed only and cannot be altered
TTL this settings controls the amount of switch hops before the packet is dropped
Advanced Options:
Secure Mode This can be enabled or disabled, and a 6-digit PIN number can be assigned. If enabled, users will
need to use this PIN to log on to the audio stream over Wi-F. Users attempting to listen to the stream without the
PIN will be unable to do so.
Network Compensation Buffer increasing this setting buffers more packets, thereby reducing the amount of
dropped packets (choppy audio), but increases latency (lip-sync delay). Decreasing this setting increases latency
and also increases the possibility of dropped packets.
Audio TX Mode Audio can be broadcast as unicast, multicast, or completely shut off.
Max Servers on Subnet When in unicast mode, up to four servers can be active at the same time. When in
Multicast mode, up to eight serves can be active. See "Additional WaveCAST Servers" on page 15 for more
details.
Multicast Address If needed, the multicast cast address can be enabled and either manually set or randomly
generated. This setting is under the Advanced options.
DHCP IP Addresses are usually preferred to manual static IP addresses unless there is a good reason to use a
Static IP scheme.
To set up a static IP Address:
1. Determine appropriate static IP, subnet mask and gateway addresses for the FM+ C.
a. If someone set up your network, they may be able to help you determine an appropriate IP address (i.e.
network system administrator).
b. There should be no other device having this same address on the network.
c. This will be an address on the same subnet as the router.
For example, if the router’s address is 192.168.1.100, the first three sets of numbers will be the same (i.e.
192.168.1), and the last number will be the number you determine for the FM+ C (i.e. .You can choose
another number instead of .100).
When you determine this address, remember or write it down. You will need it later.
2. In the web page on the Network Settings page, select 'Static' for the fields to show, then enter the above
information for the device.
3. Click Submit and Reboot when ready.
