14
3.3. DEVICE USE
2. Before starting the machine:
• check that all bolts and screws are tightened.
• lubricate the bearings as per the instructions in 3.4.
• set the roller pressure as per the instructions in 3.4.
• when using a new die for the rst time, grind it as per
the instructions in 3.4.
3. Start the tractor with the machine drive shaft
attached. The die will start to rotate.
• 5 kg of ne sand (optional),
• 1,5 l of vegetable, used or dirty oil
b) Mix all ingredients in a bucket until to prepare a
mixture like in the photo below.
EN
c) Press the mixture 80 to 90 times through the die,
until the granules coming out of the chute meet the
quality requirements.
15
REPLACEMENT / REMOVAL OF THE DIE
To replace / remove the die, follow these steps:
• Turn o the tractor to stop the machine drive shaft.
Disconnect the drive shaft from the tractor.
• Unscrew the hopper and remove it from the machine
casing.
• Remove the screws used to adjust the pressure
between the die and the rollers, and the screws
fastening the top casing. Remove the rollers.
• Remove the clamping nut lock.
• Unscrew the clamping nut with the supplied spanner.
EN
WIE
-
PM
-
2500 WIE
-
PM
-
3000
1. Preparing the granules
We recommend using the following glue (product code
10530000):
Description Modied food quality wheat starch
Form Loose powder
Colour White up to light cream
Smell and avour Typical of wheat starch
Parameters:
• Maximum humidity (%) 11,0
• pH value 5,5 – 7,5
• Viscosity > 3000 mPas
• Cold-water soluble Yes
Usage: This product is an excellent adhesive agent that has
been used in the production of various types of products,
including charcoal and hard coal briquettes, sawdust
pellets, straw and otation concentrates. It is recommended
for feed production for all animals. The use of the adhesive
requires it to be mixed it with slightly moistened raw
material (in the case of dry products). The mass is thenfed
into a briquetting machine. After the briquette has been
molded from coal dust, it must undergo a drying process.
Recommended dosing:
• charcoal dust: 5–7 %,
• hard coal dust: 1,5–5 %,
• wood pellet: 0,5–2 %,
• straw briquette: 1,5–5 %.
Packaging: multi-layer paper valve bags of 20 kg net each
(pallet of 660 kg) or big bags of 800 kg
each.
Storage: dry and covered places.
Shelf life: 12 months from the date of production.
CAUTION: The data contained in this information sheet is
based on our laboratory tests and technical
experiences. They provide a general indication of
properties, usage and application. For the proper
use of the product, it is necessary for the customer to carry
out technological tests taking into
account the specics of a given technological process.
ATTENTION! Scan the QR-code below to see the
videos to better understand the preparation and
operation of the device.
4. Place the granulate container under the chute.
5. Pour the mix into the hopper. Increase the amount of
poured material gradually to avoid clogging the die
or overloading the machine. Pouring in too much at
once may cause the die to clog.
Caution:
• if the material is too dry, it will not be pressed
properly;
• if the material is too moist, the pellets will be of poor
quality;
• the maximum length of the material particles should
be approx. 5 mm. Longer material may clog the
machine and reduce its eciency. Too large material
should be broken / cut into smaller particles.
6. After a short time, pellets will be falling into the
container under the chute. They will achieve their
nal hardness and consistency only after cooling.
7. Proceed until the mix is completely processed.
8. After nishing work, switch the device o using the
OFF button and disconnect it from the power supply.
NOTE: Do not stop the machine while making pellets
otherwise it will get clogged.
ATTENTION: do not leave the device unattended
until it has completely cooled down!
9. Clean the machine so that pellet residues do not
remain on the rolls and in the dia.
3.4. CLEANING AND MAINTENANCE
Before each cleaning, adjustment, replacement of
attachments, and also when the machine is not in use, stop
the drive by turning o the tractor. Then disconnect the
drive shaft from the tractor to avoid accidental starting.
a) Use only non-corrosive cleaners to clean the surface.
b) Store the unit in a dry, cool place, free from moisture
and direct exposure to sunlight.
c) Do not spray the device with a water jet or submerge
it in water.
d) Do not allow water to get inside the device through
vents in the housing of the device.
e) Clean the vents with a brush and compressed air.
f) The device must be regularly inspected to check its
technical eciency and spot any damage.
g) Do not use sharp and/or metal objects for cleaning
(e.g. a wire brush or a metal spatula) because they
may damage the surface material of the appliance.
h) Do not clean the device with an acidic substance,
agents of medical purposes, thinners, fuel, oils or
other chemical substances because it may damage
the device.
i) Regularly lubricate the machine as per the
instructions.
GRINDING A NEW DIE
IMPORTANT! the die is a consumable part - its
service life is approx. 300 working hours or 30 days
(daily use for approx. 6 hours). The used element is
not subject to warranty. If the wear of the die is 4
mm, replace it with a new one.
Before rst use, a new die should be polished and cleaned
using the following process:
a) Prepare
• 5kg our or saw dust,
05.05.2022
