15
4. Replace the shelf by sliding the back of the shelf into the track
in the wall of the cabinet.
5. Guide the front of the shelf into the shelf track. Be sure to slide
the shelf in all the way.
Freezer Shelf
Important information to know about glass shelves and
covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
Full-Width Shelf (on some models)
Depending on your model, the shelf may be wire or glass.
To remove and replace the freezer shelf:
1. Remove items from the shelf.
2. Lift back of shelf over stop and slide shelf straight out.
3. Replace the shelf by sliding the back of the shelf into the
tracks on walls of cabinet.
4. Be sure to slide the shelf in all the way.
Half-Width Shelf (on some models)
IMPORTANT: The half-width shelf can only be installed in the
left-hand side of the freezer compartment.
1. Remove items from the shelf.
2. Remove the shelf screw. Lift back of the shelf over the stop
and slide it out.
3. Replace the shelf by sliding the back of the shelf into the
tracks on the walls of the cabinet. Fasten the shelf screw.
Frozen Food Storage Guide
Storage times will vary according to the quality and type of food,
the type of packaging or wrap used (should be airtight and
moisture-proof), and the storage temperature. Seal the package
or container securely to avoid taste and odor transfer throughout
the product. Ice crystals inside a sealed package are normal. This
simply means that moisture in the food and air inside the package
have condensed, creating ice crystals.
Put no more unfrozen food into the freezer than will freeze within
24 hours (no more than 2 lbs to 3 lbs of food per cubic foot
[907 g per L to 1,350 g per L] of freezer space). Leave enough
space in the freezer for air to circulate around packages. The
freezer door must close tightly.
NOTE: For more information on preparing food for freezing, check
a freezer guide or reliable cookbook.
Door Rails or Trivets
SNAP ON DOOR RAILS OR TRIVETS
To remove and replace the rails or trivets:
1. Depending on your model, remove the rails or trivets by
pushing in slightly on the front of the bracket while pulling out
on the inside tab. Repeat these steps for the other end.
2. Replace the rails or trivets by aligning the ends of the brackets
with the buttons on the sides of the door liner. Firmly snap
bracket and assembly onto the tabs above the shelf as shown.
Style 1 -Door Rails
Style 2 - Trivets
DROP-IN DOOR RAILS
To remove and replace the rails:
1. Remove the rails by pulling straight up on each end of the rail.
2. Replace the rails by sliding the shelf rail into the slots on the
door.
Can Racks and Bins (on some
models)
Can Racks and Door Bins
NOTE: Can racks may be purchased as an accessory for some
models.
To remove and replace the racks/bins:
1. Remove the rack/bin by lifting it and pulling it straight out.
2. Replace the rack/bin by sliding it in above the desired support
and pushing it down until it stops.
