14
6. Insert the set screw and partially tighten (2 turns). Align
handle, then tighten the screws and set screw completely plus
an additional quarter-turn.
C
B
A
Final Steps
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
1. Check all holes to make sure that hole plugs and screws are in
place. Install the top hinge cover again. See Top Hinge
graphic.
2. Remove the cover from the base grille. Move the cover to the
opposite side.
3. Align the clips on the base grille with the screws on the bottom
of the cabinet. Push the base grille toward the cabinet until it is
flush.
4. Plug into a grounded 3 prong outlet.
5. Reset the controls. See “Operating Instructions”.
6. Return all removable door parts to doors and food to
refrigerator.
Adjust the Doors
WARNING
Excessive Weight Hazard
Use two or more people to lift the appliance door.
Failure to do so can result in back or other injury.
Your refrigerator has two adjustable levelers, one on each side, at
the base of the refrigerator. If your refrigerator seems unsteady or
if you want the doors to close more easily, adjust the level and tilt
of the refrigerator.
1. Turn the leveler to the left to raise that side of the refrigerator
or to the right to lower that side. It may take several turns to
adjust the tilt of the refrigerator.
NOTE: Having someone push against the top of the
refrigerator takes some weight off the levelers. This makes it
easier to turn the levelers.
2. Open both doors again to make sure that they close as easily
as you like. If not, tilt the refrigerator slightly more to the rear
by turning both levelers to the right. It may take several more
turns.
NOTE: To keep the refrigerator level, make the same
adjustment to each side.
3. Using a level, make sure the refrigerator is still level from side
to side. Readjust if necessary.
REFRIGERATOR AND FREEZER
FEATURES
Refrigerator Shelves
Important information to know about glass shelves and
covers:
Do not clean glass shelves or covers with warm water when they
are cold. Shelves and covers may break if exposed to sudden
temperature changes or impact, such as bumping. Tempered
glass is designed to shatter into many small, pebble-size pieces.
This is normal. Glass shelves and covers are heavy. Use both
hands when removing them to avoid dropping.
Refrigerator Shelves
The shelves in your refrigerator are adjustable to match your
individual storage needs.
Storing similar food items together in your refrigerator and
adjusting the shelves to fit different heights of items will make
finding the exact item you want easier. It will also reduce the
amount of time the refrigerator door is open, and save energy.
To remove and replace a shelf:
1. Remove items from the shelf.
2. Slide the shelf straight out to the stop.
3. Depending on your model, lift back or front of the shelf past
the stop. Slide shelf out the rest of the way.
