FUNCTIONS
P BOOSTER FUNCTION
Booster is a special mode with a power level higher than level 18, for the fastest
heating. This mode can have a dierent duration depending on the zone used
(refer to table below). After the Booster time has elapsed, the power will be
automatically reduced to level 18.
IMPORTANT: Do not use with an empty pan or oil/butter. This function is ideal
for boiling water.
NOTE: Depending on the Power Management setting, the Booster function
may not be available for certain cooking zones. Furthermore, if you set one
cooking zone to Booster and then activate another zone, the rst one will
be reduced to the maximum level available (even much lower than level 18)
to allow the second one to be used. The second cooking zone will be set or
limited based on the remaining power available on that side of the hob.
Please bear in mind as well that the power delivery may vary according to the
size and material of the cookware being used.
2
1
3
4
ZONE DESCRIPTION
Zone Nominal power
(Level 18, kW)
Power
Booster (kW)
Booster
Duration (min.)
1 or 2 2.2 3.7 10
3 2.5 3.7 10
4 1.5 2.2 5
1+2
(Flexi Zone)
2.2 3.7 10
NOTE: the values in the table refer to testing conditions as described in the normative standard for
evaluating the performance of cooking appliances.
The power shown may vary depending on the size or material of the cookware used.
FLEXIBLE COOKING ZONE FLEXI ZONE
With this function you can combine two cooking zones into a single, longer one
to accommodate rectangular, oval or elongated cookware, and use a single
setting for the whole combined zone.
To ensure the correct results, use only pots and pans with a ferromagnetic base
long enough to cover the two zones at the same time. Place the cookware in
the centre of the exible cooking rectangular area.
Refer to the gure below for examples of correct and incorrect usage.
NOTE: A large round pot used in the middle may heat up less quickly and heat
may be distributed less evenly.
IMPORTANT: With pots and pans with a ferromagnetic base of 21 cm or
smaller, it is recommended to use the single cooking zones without activating
the exible cooking mode (Flexi Zone). Place the cookware on either the
front or rear zone, then activate that zone.
If the Flexi Zone is active, the Heat Control function will not be available or
displayed on the control panel.
Refer to the gure below for examples of correct and incorrect usage.
Flexi Zone used as two individual zones
When used with two pots or pans at the same time, it is advisable to place the
rst one on the rear zone and the second on the front zone (refer to gure
below). In this case, the zones should be activated without using the exible
cooking mode (Flexi Zone).
For optimal performance, make sure both pans are centred in their respective
zones. Do not move one pot/pan o-centre to make space for the other one.
When positioning the cookware, do not go outside the cooking zone area or on
top of the control panel.
Refer to the gure below for examples of correct and incorrect usage.
AUTOMATIC FUNCTIONS
This hob provides you with some automatic functions to assist you in the cooking
process. Please note that they may not be available, depending on the power
management setting (see "Power Management" section). For example, if power
management has been set at 2.5 kW and some zones are already being used, the
remaining power might not be enough to activate an automatic function. The
hob will notify you with an acoustic signal.
MELTING
The function automatically sets the ideal power for melting. It allows
you to melt delicate food such as chocolate or butter, and keep it melted
without the risk of it burning or sticking to the pot/pan.
KEEP WARM
The function automatically sets the ideal power for keeping food warm after
cooking and before serving. Note that liquids are reduced over time when food
is kept warm.
These automatic functions are only available on standard cooking zones
(zones with the icon
).
How to activate automatic functions:
To activate the automatic functions, press the icon
.
The display will show two dimly lit icons:
(keep warm) on the top and
(melting) on the bottom.
Use the up (
) and down ( ) arrows to select the required function.
The display will show “A1” for melting and “A2” for keep warm and the
corresponding icon will become brighter.
HEAT CONTROL ASSISTED COOKING WITH TEMPERATURE
This function allows you to select and cook at the temperature you want (as you
would do with an oven), rather than using standard power levels.
With this feature, the hob will automatically adjust the heat and maintain a
stable cookware temperature, eliminating the need for constant adjustments.
This function is available only on cooking zones with the
icon .
NOTE: The displayed temperature refers to the centre of the empty cookware.
Depending on the specic cookware you are using, the temperature shown might
be dierent from the actual cookware temperature. For optimal performance, it is
advisable to place the cookware in the centre of the cooking zone and to activate
the function when there is no 'residual heat' indicator (
) active.
