EN
Daily Reference Guide
6
ATTENTION: Always unplug the appliance when cleaning it and when
performing maintenance work.Do not use ammable liquids to clean the
machine.
CLEANING THE DISHWASHER
Any marks on the inside of the appliance may be removed
using a cloth dampened with water and a little vinegar.
The external surfaces of the machine and the control pan-
el can be cleaned using a non-abrasive cloth which has
been dampened with water. Do not use solvents or abra-
sive products.
PREVENTING UNPLEASANT ODOURS
Always keep the door of the appliance ajar in order to avoid moisture from
forming and being trapped inside the machine. Clean the seals around the
door and detergent dispensers regularly using a damp sponge. This will
avoid food becoming trapped in the seals, which is the main cause behind
the formation of unpleasant odours.
CHEKING THE WATER SUPPLY HOSE
Check the inlet hose regularly for brittleness and cracks. If damaged, re-
place it by a new hose available through our After-Sales Service or your
specialist dealer. Depending on the hose type:
If the inlet hose has a transparent coating, periodically check if the colour
intensies locally. If yes, the hose may have a leak and should be replaced.
For water stop hoses: check the small safety valve inspection window (see
arrow). If it is red, the water stop function was triggered, and the hose must
be replaced by a new one. For unscrewing this hose, press the release but-
ton while unscrewing the hose.
CLEANING THE WATER INLET HOSE
If the water hoses are new or have not been used for an extended period of
time, let the water run to make sure it is clear and free of impurities before
performing the necessary connections. If this precaution is not taken, the
water inlet could become blocked and damage the dishwasher.
CLEANING THE FILTER ASSEMBLY
Regularly clean the lter assembly so that the lters do not clog and that
the waste water ows away correctly.
Using the dishwasher with clogged lters or foreign objects inside the l-
tration system or spray arms may cause unit malfunction resulting in loss of
performance, noisy work or higher resources usage.
The lter assembly consists of three lters which remove food residues
from the washing water and then recirculate the water.
The dishwasher must not be used without lters or if the lter is loose.
At least once per month or after every 30 cycles, check the lter assembly
and if necessary clean it thoroughly under running water, using a non-me-
tallic brush and following the instructions below:
1. Turn the cylindrical lter A in an anti-clockwise direction and pull it out
(Fig 1). It is important when reinstalling the lter that the two trian-
gles shown on the zoom meet.
2. Remove the cup lter B by exerting a slight pressure on the side aps
(Fig 2).
3. Slide out the stainless-steel plate lter C (Fig 3).
4. In case you nd foreign objects (such as broken glass, porcelain, bones,
fruit seeds etc.) please remove them carefully.
5. Inspect the trap and remove any food residues. NEVER REMOVE the
wash-cycle pump protection (shown by an arrow) (Fig 4).
CARE AND MAINTENANCE
2
1
4
3
A
A
B
C
After cleaning the lters, replace the lter assembly and x it in position cor-
rectly; this is essential for maintaining the ecient operation of the dishwasher.
CLEANING THE SPRAY ARMS
On occasions, food residue may
become encrusted onto the
spray arms and block the holes
used to spray the water. It is
therefore recommended that
you check the arms from time
to time and clean them with
asmall non-metallic brush.
To remove the upper spray you
must remove it together with
the manifold.
The Top Rack has a xed wash
tube with all the wash nozzles
facing upward. To clean it you can slide the rack out and with a tweezer
remove items that may be lodged in the nozzles.
The lower spray arm may be removed by
pulling it upwards and rotating it an-
ti-clockwise. Mounting back the spray
arm is by pulling it down and rotating it
clockwise.
The ceiling spray arm may be removed
by pressing it up and then rotating it
anti-clockwise. Mounting back the spray
arm is by pulling it upwards and rotating
it clockwise.
