EN
Daily Reference Guide
5
WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or
water tap is closed .
SENSING - When the sensor is detecting the soil level an
animation appears in the display (around 20 min.) and the cycle
duration is updated. SENSING is for the level of soiling on the
dishes and it is present for all cycles (excepting Eco) adjusting the program
accordingly.
CYCLE COUNTER - This feature shows the number of cycles the
dishwasher has performed.
For the number of cycles from 0-999, a xed number will be displayed.
Example for 25 cycles.
When the cycle number is higher than 1000, the number will scroll in
the display. The “_” represents the “
.
”, as for instance: 1.000 = 1_000,
13.947= 13_947 (the number will scroll for 3 times).
Example for
13.947 cycles:
After the cycle visualization, the display will return to visualize
„ ”
.
NOTE: The dishwasher may have already performed about 30 cycles.
This is due to the extended quality process carried out during
production. It guarantees higher product quality.
LOADING THE RACKS
CAPACITY: 15 standard place-settings
TOP RACK
The top rack pro-
vides a targeted
cleaning Wash Zone
for bowls, mugs,
even big plates and
cutlery that you’d
normally load in the
lower racks, making
extra space for the rest of the day’s dishes.
A separate arrangement of the cutlery makes
collection easier after washing and improves
washing and drying performance.
Knives and other utensils with sharp edges
must be positioned with the blades facing
downwards.
UPPER RACK
Load delicate and light dishes: glasses, cups,
saucers, low salad bowls.
The upper rack has tip-up supports which can
be used in a vertical position when arranging
tea/ dessert saucers or in a lower position to
load bowls and food containers.
(loading example for the upper rack)
ADJUSTING THE HEIGHT OF THE UPPER RACK
The height of the upper rack can be adjusted: a high po-
sition to place bulky crockery in the lower basket and a low
position to make the most of the tip-up supports by cre-
ating more space upwards and avoiding collision with the
items loaded into the lower rack.
The upper rack is equipped with an Upper Rack height
adjuster (see gure), without pressing the levers, lift it up
by simply holding the rack sides, as soon as the rack is sta-
ble in its upper position. To restore to the lower position,
press the levers A at the sides of the rack and move the ba-
sket downwards.
We strongly recommend that you do not adjust the height of the rack
when it is loaded. NEVER raise or lower the basket on one side only.
FOLDABLE FLAPS WITH ADJUSTABLE POSITION
The side foldable aps can be folded or unfolded
to optimize the arrangement of crockery inside
the rack. Wine glasses can be placed safely in
the foldable aps by inserting the stem of each
glass into the corresponding slots. In the case
of the high position of the upper rack, aps
cannot remain in the vertical position.
Depending on the model:
• to unfold the ap there is needed to slide it up
and rotate or release it from the snaps and pull
it down.
• to fold the flap there is needed to rotate it and slide
the flap down or pull it up and attach the flap to the snaps.
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should ide-
ally be placed at the sides to avoid interferences with the spray arm.
The lower rack has tip-up supports which can be used in a vertical position
when arranging plates or in a horizontal position (lower) to load pans and
salad bowls easily.
(loading example for the lower rack)
POWER CLEAN®
Power Clean® uses the special water jets in
the rear of the cavity to wash more intensive-
ly the highly dirty items. The lower rack has a
Space Zone, a special pull-out support in the
rear of the rack that can be used to support
frying pans or baking pans in an upright po-
sition, thus taking up less space.
Placing the pots/casseroles faced to the
Power Clean® component please activate
the POWER CLEAN on the panel.
How to use the Power Clean®:
1. Adjust the Power Clean® area G folding
down the rear plate holders to load pots.
2. Load pots and casseroles inclined verti-
cally in the Power Clean® area. Pots have
to be inclined towards the powerful wa-
ter jets.
CUTLERY BASKET
It is tted with top grids for
improved cutlery arrange-
ment.
It must only be positioned at
the front of the lower rack.
Knives and other utensils
with sharp edges must be
placed in the cutlery basket
with the points facing downwards or they must be positioned horizon-
tally in the tip-up compartments on the upper rack.
