Daily Reference Guide

PROGRAMS TABLE

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@europeanappliances.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Door is opened before the programm has been ended. This is to improve the drying eciency. Wait until the time has reached 00:00 to unload the dishwasher

**) Not all options can be used simultaneously.

***) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration by up to 20 min.

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in

the specific area. This option is recommended for washing pots and casseroles

(Please refer to the Power Clean® loading section).

EXTRA DRY - The higher temperature during the final rinse and the

extended drying phase allow improved drying. The EXTRA DRY option

results in the lengthening of the wash cycle.

DELAY - The start of the program may be delayed for a period of time

between 0:30 and 24 hours.

1. Select the program and any desired options. Press the DELAY

button (repeatedly) to delay the start of the program. Adjustable from

0:30 to 24 hours. Once the 24 hours setting is reached, press the DELAY

another time to deactivate the DELAY function.

2. Close the door and press the START/Pause button. The timer will begin

counting down.

3. Once this time has elapsed, the indicator light switches o and the

program begins automatically.

The DELAY function cannot be set once a program has been started.

NaturalDry -

It is aconvection drying system which automatically opens the

door during/after drying phase to ensure exceptional drying performance

every day. Door opens at the temperature that is safe to your kitchen furniture.

As additional steam protection, special designed protection foil is added

together with the dishwasher.

To see how to mount protection foil please refer to the INSTALLATION

GUIDE. This feature is active by default, but it is possible to deactivate it in

the “SETTINGS MENU” .

HALF LOAD - If there are not many dishes to be washed, HALF LOAD

is used to save water, electricity or time, depending on the selected

program. Remember to halve the amount of detergent.

OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator

lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rap-

idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.

DESCALE – Alarm - Limescale accumulation was detected on the

internal components of the appliance. Check if the Water Hardness

Setting is at the correct value and salt is present in the salt container

(see FIRST TIME USE), then use a descaling product (WPro brand is

recommended) with the Self-Clean program. After a successful descaling,

the icon will stop being displayed.

If the actions above are not performed, product performance will deteriorate.

DESCALE warning will start blinking and «dES» alarm will appear on the

display. If still no action is taken, the appliance will only allow a certain number

of cycles to be started (indicated during «dES» alarm display) and then will

be BLOCKED to prevent component damage, with only the Self-Clean

program available. Performing a full descaling will unblock the product.

In the case of extremely high amounts of limescale, descaling may have to

be performed twice to be ecient .

OPTIONS AND FUNCTIONS

KEYLOCK - A long press (for 3 seconds) of EXTRA DRY button, will

activate the KEYLOCK function. The KEYLOCK function will block the

control panel except for the ON/OFF button. To deactivate the KEYLOCK,

long press again.

FAVOURITE  The FAVOURITE program may be saved and will be easily

accessible. Find the program using PREVIOUS/NEXT, and then press

the FAVOURITE program button for 3 seconds.

Program Programs description

Drying phase

NaturalDry

Available options

**)

Duration

of wash

program

(h:min)

***)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware, that

for this use, it is the most ecient program in terms of its combined

energy and water consumption, and that it is used to assess compli-

ance with the EU Ecodesign legislation.

4:30 9.9 0.65

Auto Intensive 65° - Automatic program for

heavily soiled dishes and pans.

Senses the level of soil-

ing on the dishes and

adjusts the program

accordingly. When the

sensor is detecting the

soil level an animation

appears in the display

and the cycle duration

is updated.

2:25 -3:10 17.0 -25.0 1.30 -1.70

Auto Mixed 55° - Automatic program for nor-

mally soiled dishes with dried food residues.

1:20 -3:20 7.5 -20.5 0.75 -1.20

Auto Fast 50° - Automatic program for nor-

mally and lightly soiled dishes. The everyday

cycle that ensures optimal cleaning and dry-

ing performance in a shorter time.

1:00 -1:50 8.0 -16.0 0.70 -1.10

Rapid 45° - Program is recommended for limited amount of lightly-soiled

dishes with no dried food residues. Does not include the drying phase.

0:30 - 0:40 10.5 -15.0 0.55 - 0.65

Crystals 45° - Program for delicate items, which are more sensitive to

high temperatures, for example, glasses and cups.

1:40 -1:50 12.5 -17.0 0.95 -1.20

Silent 55° - Suitable for night-time operation of the appliance. Ensures

optimal cleaning and drying performance with the lowest noise emission.

3:50 - 4:10 10.5 -14.5 0.80 -1.15

Sanitizing 65° - Normally or heavily soiled crockery, with additional anti-

bacterial wash. Can be used to perform maintenance of the dishwasher.

1:55 - 2:10 12.0 -19.0 1.40 -1.80

Prewash - Used to refresh crockery planned to be washed later. Node-

tergent is to be used with this program.

0:12 4.5 0.10

P10

Self Clean 65° -

Program to be used to perform maintenance of the

dishwasher, to be carried out only when the dishwasher is EMPTY using

specic detergents designed for dishwasher maintenance.

1:15 12.7 1.10
