- 14 -
Remote controller
Function description of buttons (J1-3A)
1. ON/OFF BUTTON
Starts or Stops the appliance by pressing this button.
2. MODE BUTTON
Used to select the operation mode in sequence of Cooling, dry,
fan only or heating.
3. FAN BUTTON
Used to select fan speed in sequence auto, high, medium or low.
4-5.TEMPERATURE BUTTON
Used to select the room temperature. Used to set time in timer
mode and real time clock.
6. AUTO BUTTON
Sets or cancels auto operation. In this function, the air
conditioner will automatically adjust to the most comfortable
temperature according to the live room temperature.
7. SWING U/D BUTTON
Stops or starts horizontal adjustment louver swinging and sets
the desired up/down airow direction.
By pressing the L/R swing for 6 times, the Wi-Fi will be activated.
8. SWING L/R BUTTON
Stops or starts vertical adjustment louver swinging and sets the
desired left/right airow direction.
9. AROUND U BUTTON
Used to set or cancel Around U function.
In this function, AC can sense the ambient temperature through
the remote control and adjust the cooling capacity accordingly.
10. TIMER ON/CLOCK BUTTON
Used to set the current time.
Used to set or cancel the timer on operation.
11 TIMER OFF BUTTON
Used to set or cancel the timer o operation.
12. JET BUTTON
Used to start or stop the fast cooling or heating mode.
13. DIM BUTTON
Used to turn on or turn o display light on indoor unit.
14. POWER SAVE BUTTON
Used to start or stop the power save operation.
15. SELF CLEAN BUTTON
Used to set self clean operation.
- When the Air conditioner and Remote controller are in standby,
and the mode of remote controller is in Cooling or Dry, then
press this button to start self clean ,the indicator
will
display on LCD.
- Press ON/OFF or AUTO or MODE button can exit the self
clean,then the indicator will disappear.
- After the clean process nished, the air conditioner will return
to Cooling or Dry as preset,while the indicator on remote
controller will display for about 30 mins.
16. SUPER SILENT BUTTON
Used to start or stop the super silent operation to have a low
noise environment.
17. SLEEP BUTTON
Press the SLEEP button, and the operation mode changes fro
ADULT Sleep 1> ELDERLY Sleep 2> YOUTH Sleep 3> CHILD Sleep
4 to closed SLEEP mode.
Adjust the temperature curve according to dierent SLEEP
modes. The temperature curve is customized within 8 hours
according to the needs of dierent groups of people.
1
2
3
4
5
6
7
8
9
10
11
12
13
17
14
15
16
Symbols on RC display
Cooling indicator Sleep 1 indicator Auto fan speed
Jet indicator
Dry indicator Sleep 2 indicator High fan speed
Signal transmission
Fan only indicator Sleep 3 indicator Medium fan speed
O
O
N
N
O
O
F
F
F
F
Display set timer
Heating indicator Sleep 4 indicator Low fan speed
Display current time
Auto indicator Around U indicator Super silent indicator
Display set temperature
Self clean indicator
Power save indicator
PROTECTION
Operating condition
The protective device maybe trip and stop
the appliance in the cases listed below.
Heating Outdoor air
temperature is
over 24°C
Outdoor air
temperature is
below -7°C
Room temperature
is over 27°C
Cooling Outdoor air
temperature is
over 43°C
Room temperature
is below 21°C
Dehumidifying Room temperature
is below 18°C
If the air conditioner runs in COOLING or
DRY mode with door or window opened
for a long time when relative humidity is
above 80%, dew may drip down from the
outlet.
Features of protection device
Wait at least 3 minutes before restarting
the unit after operation stops or changing
mode during operation. After connecting
to power supply and turning on the
appliance immediately, a delay of 20
seconds may occur before it starts to
operate. If all operation has stopped,
press ON/OFF button again to restart.
Timer should be set again if it has been
cancelled.
Features of COOLING mode
Anti-freezing
When the temperature of the indoor
heat exchanger drops to 0° or below,
compressor will stop working to protect
the appliance.
Features of HEATING mode
Preheating
In order to prevent cool air blowing, 2-5
minutes are necessary to preheat the
indoor unit at HEATING operation start.
The indoor fan will not work during
preheating.
Defrosting
In HEATING operation the appliance will
defrost (de-ice) automatically to raise
eciency. This procedure usually lasts
6-10 minutes. During defrosting, fan stops
running and running indicator ashes.
After defrosting is completeed, it returns
to HEATING mode automatically.
