11
EN
NOTE: In installation where both sides and the rear
of the refrigerator are not enclosed by cabinetry
e.g. the refrigerator is placed against a wall, the
clearance between the rear of refrigerator and the
wall should not be greater than 75mm.
You refrigerator uses energy efficient
components that may produce dierent noises
(Refer “Noises” page for examples) to your
old refrigerator. Occasionally a gurgling sound
of refrigerator flowing or the sound of parts
expanding and contracting can be heard. These
noises are quite normal.
LOCATING THE REFRIGERATOR
Installing your refrigerator
1. Roll the refrigerator into place.
The rollers are designed for forward or
backward movement only. They are not
castors. Moving the refrigerator sideways
may damage your floor and the rollers.
Before moving your refrigerator ensure
height adjusting nut and the stability foot
are fully wound up o the floor.
2. Wind the large height adjusting nut under
door hinge down until the refrigerator is
tilted back by 10mm (see diagram).
Height adjusting nut
Fixed rear rollers
10-15mm
3. Wind the large height adjusting nut on the
handle side down until the refrigerator is
level and stable. If you have difficulty
winding the nut or height adjusting foot
down, have someone tilt the refrigerator
back so you have better access.
stability foot
wound up
4. INSTALLING YOUR NEW APPLIANCE
Unpacking
ENVIRONMENT
Most of the packing materials are
recyclable. Please dispose of those
materials through your local recycling
depot or by placing them in appropriate
collection containers.
Important – check for any damages or marks.
If you find the refrigerator is damaged or marked,
you must report it within 7 days should you wish to
claim for damage/ marks under the manufacturers
warranty. This does not aect your statutory rights.
Clean the refrigerator thoroughly according to
instruction, and wipe away any dust that has
accumulated during shipping.
Check that the floor is level. If it is not then adjust
the provided leveling leg so product is level and
stable.
We recommend that you let your refrigerator run
for two to three hours before you put any food in
it. This will allow you to check that it is operating
properly and that enough cool air is going to the
freezer.
Clearance around your refrigerator;
•
Allow a minimum of 30mm clearance on both
sides of the refrigerator.
•
Allow 50mm clearance at the back of the
refrigerator.
•
Allow a minimum of 10mm clearance above the
hinge cover.
•
If you do not have a cupboard with allowance
for air flow above the refrigerator, the
recommended clearance area on top increases
to 90 mm.
30mm
30mm
DOOR
50mm
CABINET
airspace
Recommended
X
90 mm
10 mm
Model
X
WTM3100*
WTM3400*
350 mm
WTM4302*
430 mm
WTM5002*
455 mm
•
When positioned in a corner area, spacing a
minimum of Xmm (Distance depends on the
model as per the table above)on the hinge side
will allow the doors to open enough to enable
the removal of bins and shelves.
