12
|
English
MAINTENANCE
WARNING
Before inspecting, cleaning or servicing the unit, stop the motor, wait for all moving parts to stop, and
disconnect the battery pack from the string trimmer. Failure to follow these instructions can result in serious personal injury or
property damage.
WARNING
Always wear eye protection with side shields marked to comply with ANSI Z87.1. Failure to do so could
result in objects being thrown into your eyes resulting in possible serious injury.
NOTICE
Periodically inspect the entire product for damaged, missing, or loose parts such as screws, nuts, and caps.
Secure all fasteners and caps. Do not operate this product if parts are missing or damaged.Please contact customer service.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial sol-
vents and may be damaged by their use. Use clean cloths to remove dirt, dust, oil, and grease.
WARNING
Do not let brake fluids, gasoline, petroleum-based products, or penetrating oils come in contact with plas-
tic parts. Chemicals can damage, weaken, or destroy plastic which can result in serious personal injury.
SPOOL REPLACEMENT
Use only 0.065 in. diameter round or twisted or 0.080 in. diameter twisted line. Use original manufacturer’s replacement line for best
performance.
1. Remove the battery pack.
2. Push in tabs on side of spool retainer.
3. Pull spool retainer up to remove.
4. Remove the old spool.
5. To install the new spool, be sure the line is captured in the slot on the new spool. Be sure the end of the line is extended approx-
imately 6 in. beyond the slot.
6. Install the new spool so that the line and slot align with the eyelet in the string head. Thread the line into the eyelet.
7. Pull the line extending from the string head so the line releases from the slot in the spool.
8. Reinstall the spool retainer by depressing tabs into slots and pushing down until spool retainer clicks into place.
LINE REPLACEMENT
1. Remove the battery pack.
2. Remove the spool retainer.
3. Remove the spool from the string head.
NOTE: Remove any old line remaining on the spool.
4. Cut a piece of line approximately 9 ft. long.
5. Use only 0.065 in. diameter round or twisted or 0.080 in. diameter twisted line.
6. Insert the line into the anchor hole in the upper part of the spool. Wind the line around the upper part of the spool clockwise, as
shown by the arrows on the spool. Place line in the slot on upper spool flange, leaving about 6 in. extended beyond the slot. Do
not overfill. After winding the line, there should be at least 1/4 in. between the wound line and the outside edge of the spool.
7. Replace the spool retainer, spool, and the spool retainer.
STORING THE STRING TRIMMER
• Remove the battery pack.
• Clean all foreign material from the trimmer.
• Store it in a place that is inaccessible to children.
• Keep away from corrosive agents.
