159272A Page 9 of 18
© Copyright 2018 WESCO Industrial Products, LLC. Specifications subject to change. Not responsible for errors or omissions.
Scale Pallet Truck
(Part # 272936 & 272938)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO PALLET
TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
4. ADJUSTING RELEASE DEVICE
The Control Handle (117) is located on the Draw-Bar of the truck and can be adjusted to three
different positions:
Raise -handle down
Drive -handle in center position
Lower -handle up, the lever moves back to the drive position when released.
If however they have been changed, you can adjust according to following step:
4.1 If the forks elevate while pumping in the DRIVE position, turn the Adjusting Nut (104) on the
Adjusting Bolt (103) clockwise until pumping action does not raise the forks and the DRIVE position
functions properly.
4.2 If the forks descend while pumping in the DRIVE position, turn the Nut (104) counter-clockwise
until the forks do not lower.
4.3 If the forks do not descend when the Control Handle (117) is in the LOWER position, turn the Nut
(104) clockwise until raising the Control Handle (117) lowers the forks. Then check the DRIVE
position according to item 4.1 and 4.2 to be sure the Nut (104) is in the proper position.
4.4 If the forks do not elevate while pumping in the RAISE position, turn the Nut (104) counter-
clockwise until the forks elevate while pumping in the RAISE position. Then check the LOWER
and DRIVE position according to item 4.1, 4.2 and item 4.3.
5. MAINTENANCE
5.1 OIL
Please check the oil level every six months. The oil can be hydraulic oil: ISO VG32, its viscosity should
be 30cSt at 104°F (40°C), total volume is about 0.4lt.
5.2 AIR REMOVAL
Air may contaminate the hydraulic oil through use during transportation or pumping up to a position. It
can cause the forks to not elevate while pumping in the RAISE position. The air can been cleared out by
setting the control handle (117) to the LOWER position, then moving the draw-bar up and down
repeatedly.
5.3 DAILY CHECK AND MAINTENANCE
Check the pallet truck daily to limit wear as much as possible. Pay special attention to the wheels and
the axles because thread, rags, etc. may block the wheels. The forks should be unloaded and set to the
lowest position when not in use.
5.4 LUBRICATION
All bearings and shafts are provided with long-life grease at the factory. Long-life grease only needs to
be applied at monthly intervals or after each thorough cleaning of the
lubrication points.
