Page 6 of 7
©Copyright 2016 WESCO Industrial Products, Inc. Specifications subject to change. Not responsible for errors or omissions. 159290A
Pneumatic Pallet Leveler
(Part # 272696)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO PALLET
LEVELER READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
4. TROUBLE SHOOTING
No
Problem Causes Solutions
1 Lowers too easily
- Not enough air pressure - Add air
2 Does not lower enough
- Excessive air pressure - Release air
3
The top of the unit rotates away from
you
- The base frame of the unit may not be level - Level the unit
4 Turntable does not smoothly rotate
- Worn turntable support bearings - Replace bearings under table
5. MAINTENANCE
Every 90 days of operation or as use warrants,
• Check for loose hardware and signs of excessive wear.
• Make sure that operating surface of unit is firm, level and clean of debris.
6. PARTS INFORMATION
6.1 AIR TANK ASSEMBLY PART DIAGRAM
6.2 AIR TANK ASSEMBLY PARTS LIST
Item Part Number Item Description Qty.
1 054664-05-02 Pop-Safety Valve with Air Fill (Schrader) Valve 1
2 054664-02 Air Tank 1
3 054664-05-05 Air Pressure Gauge 1
4 054640 Air Line Kit 1
WARNING! DO NOT SET
AIR PRESSURE TO OVER
80 PSI WITH PALLET
LEVELER UNLOADED
