Folding Handle Scissors Lift Table
(Part # 260207 & 260208)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR SCISSORS LIFT TABLE,
READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
3. ASSEMBLY
Handle Installation: According to the General Assembly Part Diagram (Page 9), fix the handle (1) to
mounting hole of the truck body (18) with bolt (64), spring washer (63), flat washer
(62), then screw down the bolt (64) with wrench.
Foot Lever Mounting: Insert the foot lever (47) into the hole of the square bar (60), screw in the screw
(42), then put in the plain washer (6) and the spring washer (11) respectively and
screw down the nut (12).
4. OPERATION
Raise:
Step on the foot lever several times to raise the working table.
Lower:
Lift the handle knob upward slowly, and open the one-way valve to make the working table
descend slowly.
Transportation:
Release the brake open before moving the truck.
5. MAINTENANCE
It is very important to conduct necessary maintenance and upkeep so as to prolong the service life and
safety of the lift table.
Please check the lift table before operation according to the following items:
1) Any distortion or bending of various sections of the lift table.
2) Check the brake of the truck and the condition of the wheels.
3) Check for oil leakage in the hydraulic system.
4) Add or fill lubricant to each friction surface before daily operation.
5) If there is any failure, the lift table should be repaired at once, then it can return to operation.
6) Change the hydraulic oil every twelve months, choose the following or close brand hydraulic oil
according to the climate conditions of different areas:
a. YBN32 is adaptive under the environment temperature of -10~+40°C.
b. YCN32 is adaptive under the environment temperature of -20~+40°C.
7) Hydraulic Oil Change Procedure:
a. Screw out the sealing screw 11 of the Pump Part Diagram (Page 6) with wrench.
b. Raise the hand knob.
c. Twist off screw 36 of the oil plug and fill in hydraulic oil.
8) Items 1, 3, 4, 21, 29, 32, 40, 43, 47, 48, 33, 41 and 45 of the Pump Part Diagram (Page 6) are seal
components of rubber, polyurethane and nylon. The general service time is two years. After
exceeding two years, it will affect the service performance. It is recommended to change them in
every two years.
