WESAUDIO
9/14/22
_PHOEBE USER MANUAL
13
6. Gain
Unit operates in different gain ranges for microphone, line, and instrument modes:
• Microphone GAIN: 20dB – 75dB
• LINE GAIN: -10dB – 20dB
• Instrument GAIN: -30dB – +25dB
If 75dB of GAIN isn’t enough, by engaging low input impedance mode (300 OHM) signal will also be
raised few more dB.
7. VU Metering
Front panel and Plug-in meter shows output value before the PAD – it visualizes Gain Level indication.
Front LEDs will all become RED when CLIP is detected.
8. Stereo vs Mono
_PHOEBE is single slot mono preamplifier. However due to its digital control it is possible to link to
modules into stereo operation – just open Stereo plug-in and connect 2 devices! From now on all controls
maybe link in a relative way, so just turn one knob, and second channel will follow!
9. Front vs Rear
_PHOEBE takes advantage over digital control and provides two memory banks:
• FRONT bank A.
• REAR bank B.
That means that activating Rear or Front, different values of parameters will be engaged on the
analog circuit – it works in very similar ways like on plug-ins or our other units, with a difference that
activating A (Front) will always enable front panel XLR/TRS socket, and B (REAR) will activate rear XLR
on the chassis. That makes it possible to permanently connect two different sources, e.g., Microphone
to rear panel of the chassis, and DI or Line level to front panel XLR/TRS socket – now by engaging Rear
or Front, different sets of parameters will be used for each of those modes, so even without a plug-in we
can easily switch between those two sources and settings using one magic button!
Front panel socket supports following signals:
• Microphone (XLR)
• Line (XLR)
• Instrument (TS)
