WESAUDIO
9/14/22
_PHOEBE USER MANUAL
12
1. FRONT/REAR SWITCH – Switch which changes input source between back XLR socket
(LINE/MICROPHONE) and front panel XLR/TS socket (LINE/MICROPHONE/INSTRUMENT). HiZ
LED is engaged when TRS cable is detected in the socket and FRONT mode is engaged.
2. 300 OHM IMPEDANCE – this button engages 300-ohm impedance (instead of 1200-ohm default
impedance).
3. PHASE – this button inverts the phase.
4. PHANTOM POWER – engages +48V phantom power. Please note that if LINE mode or HiZ
mode is active, this option will be automatically disabled.
5. GAIN knob – Sets the gain of the preamplifier / Push the encoder to toggle between LINE and
MICROPHONE mode.
6. VU METER – VU meter shows output level up to +24dBu, all LEDs turns RED when internal CLIP
is detected.
7. PAD – passive attenuator up to 15dB in 1dB step.
8. FRONT PANEL XLR/TRS – socket is activated when FRONT mode is active, it supports LINE,
INSTRUMENT or MICROPHONE signals.
9. USB – module control USB port,
10. DATA LED – indicates that data is being sent from DAW to device,
11. H-LINK LED – indicates state of host-module connection,
