13
EXPLODED VIEW & PARTS LIST
HT-400AF and HT-427AF
M021B 2M-308086 Owners Manual for Autofill Built-In Bain Marie Warmers
THERMOBULB
BRACKET
D8-303352
BALL VALVE
2V-47847
FRONT/REAR
SHROUD
P2-304105
DRAIN SCREEN
P2-31869
ADAPTER BAR
P2-301893
SIDE
SHROUD
P2-303359
ELEMENT CLIP
2C-30397
HEATING
ELEMENT
2N-46660UL
ELEMENT PAN
WS-501759
HT-400AF
BOTTOM
COVER
P2-301870
SIDE
SHROUD
P2-302882
FRONT/REAR
SHROUD
P2-304106
DRAIN SCREEN
P2-31869
ADAPTER BAR
P2-303012
HT-427AF
ELEMENT CLIP
2C-30397
HEATING
ELEMENT
500706
THERMOBULB
BRACKET
D8-303352
ELEMENT PAN
P2-302883
BOTTOM
COVER
P2-302996
BALL VALVE
2V-47847
LIGHT SIGNAL
RED 2J-35687
THERMOSTAT
2T-45917
2T-46551, 6FT LEADS
MOUNTING BRACKET
THERMO D8-303352
CONTROL KNOB
ASSEMBLY 2R-40498
CONDUIT FITTING 90 DEGREE
2K-34136X
CONTROL BOARD
2E-306865
SOLENOID VALVE
2E-46529
TERMINAL BLOCK
WS-50131
WATER LEVEL
PROBE WS-503713
ELBOW 2K-48198
NIPPLE 2K-48197
BACKFLOW
PREVENTOR
2V-47650
HOSE FITTING
2K-47662STRAIGHT
HOSE CLAMP
2C-46591
WATER HOSE
36” P2-46587
72” P2-46587A
IL2455-021B, Rev. - 4/3/12
