12
EXPLODED VIEW & PARTS LIST
HT-300AF and HT-327AF
M021B 2M-308086 Owners Manual for Autofill Built-In Bain Marie Warmers
DRAIN SCREEN
P2-31869
ELEMENT CLIP
2C-30397
HEATING
ELEMENT
2N-300706UL
THERMOBULB
BRACKET
D8-303352
ELEMENT PAN
P2-302883
ADAPTER BAR
P2-303012
SIDE
SHROUD
P2-302882
FRONT/REAR
SHROUD
P2-304105
HT327AF
BALL VALVE
2V-47847
THERMOBULB
BRACKET
D8-303352
BALL VALVE
2V-47847
FRONT/REAR
SHROUD
P2-304105
DRAIN SCREEN
P2-31869
ADAPTER BAR
P2-301893
SIDE
SHROUD
P2-303359
ELEMENT CLIP
2C-30397
HEATING
ELEMENT
2N-46660UL
ELEMENT PAN
WS-501759
HT300AF
BOTTOM
COVER
P2-301869
BOTTOM
COVER
P2-301869
LIGHT SIGNAL
RED 2J-35687
CONTROL PANEL
I7-Z12221
THERMOSTAT
2T-45917
2T-46551, 6’ Leads
MOUNTING BRACKET
THERMO D8-303352
CONTROL KNOB
ASSEMBLY 2R-40498
CONTROL BOX
P2-306960
CONDUIT FITTING 90 DEGREE
2K-34136X
CONTROL BOARD
2E-306865
SOLENOID VALVE
2E-46529
TERMINAL BLOCK
WS-50131
WATER LEVEL
PROBE WS-503713
ELBOW 2K-48198
NIPPLE 2K-48197
BACKFLOW
PREVENTOR
2V-47650
HOSE FITTING
STRAIGHT, 2K-47662
HOSE CLAMP
2C-46591
WATER HOSE
36” P2-46587
72” P2-46587A
IL2460-021B, Rev. - 4/3/12
