18
• Route a 6 mm channel into the
Ultra-12panelfortheoorsensor
to be recessed into.
• Install the sensor at least
300 mm into the heated area it
will be controlling. It should be
located centrally between parallel
runs of pipe and not in an area
inuencedbyotherheatsources.
• The sensor can be secured to the
suboorwithtabsoftape.
• Measure and cut the pipe so
thatitreachesboththeowand
return ports on the manifold.
• Refer to the manifold manual
for detailed information on
mounting, pressure testing and
commissioning.
6 7
Test the resistance of the oor
sensor at this stage
Step 4 - Lay the pipe
