7
Important installation information
On delivery of the Econna-12 panels ensure that they are stored
in a dry weather tight area, away from chemicals and that they are
stacked horizontally and raised o the ground. The panels must
not be exposed to moisture or high humidity.
The moisture content of the Econna-12 panels and plywood layer
should be no higher than 10 % and they should ideally acclimatised
together before installation.
Perform a site inspection. You will need to conrm that all
measurements and other requirements on site match your
working drawings. Ensure that all areas are correctly prepared, dry
and protected from weather.
Inspect the site for possible hazards that could damage the
Warmup pipe, such as nails, staples, materials or tools.
Ensure that insulation is installed between the joist in line with
building regulations. Joists must be level and even, clear of debris
and without any surface deviations such as knots or nails.
Dust particles may become airborne when cutting wood or
insulation products. Therefore please follow relevant health and
safety rules when cutting the panels or insulation by using a mask,
goggles, gloves and ensuring adequate ventilation.
Econna-12 panels are a structural oor deck therefore extra pipe
channels must not be routed into the panels as this would weaken
the system.
Ensure the end of each Econna-12 panel falls on a centre line of a
joist. The shortest length of panel should be supported across a
minimum of three joists. If a shorter panel is required it must be
supported by noggins. Ensure that each row of panels has a group
of return loops at each end.
Use a pipe cutter designed for plastic pipe ensuring that there
are no burrs on the pipe ends. It is important to achieve
a clean cut.
Do not pull pipe from the coil while it is sitting at. It must be
unwound from the coil, rotating the coil as the pipe is pulled from
the inside.
Do not force the pipe into bends. It is easier to lay the pipe with
a large radius and then gently pull the pipe to the required bend.
The minimum bending radius is 5 times the diameter of the pipe.
Do not kink the pipe. Excessive bending of the pipe can cause it to
kink, where this occurs ow may be obstructed or reduced. Kinked
pipe must be repaired or replaced. To repair a kink, straighten
the pipe and simply heat the area with a hot air gun until the kink
disappears.
Before installing the oor nish, its suitability for use with
underoor heating and its maximum operating temperature
should be checked against required operating conditions.
Underoor heating performs the most eciently with conductive,
low resistance oor nishes such as stone and tiles. Consideration
should be given to the thermal resistance and temperature limits
of the chosen oor covering and its impact on the system heat
output.
