14
• Route a 6 mm channel into the
Econna-12 panels for the oor
sensor to be recessed into.
• Install the sensor at least
300 mm into the heated area it
will be controlling. It should be
located centrally between parallel
runs of pipe and not in an area
inuenced by other heat sources.
• The sensor can be secured to the
suboor with tabs of tape.
• Measure and cut the pipe so
that it reaches both the ow and
return ports on the manifold.
• Refer to the manifold manual
for detailed information on
mounting, pressure testing and
commissioning.
6 7
Step 3 - Lay the pipe
• Before installing the nal
Econna-12 panel, drill another
12.5 mm hole in this last panel at
a 20° angle where the return pipe
needs to drop into the batten
space.
• Feed the pipe through the hole
through to the manifold location,
notching/drilling the joists as
required in line with building
regulations.
• Glue and screw the nal
Econna-12 panel in place
following the procedures in
Step 2.
8 9
Test the resistance of the oor
sensor at this stage
