17
Model 7iE-01-XX-YY
Operating Voltage 230 V AC : 50 Hz
Protection Class Class II
Max. Load 16A (3680W)
Rated impulse voltage 4000V
Automatic action 100,000 cycles
Disconnection means Type 1B
Pollution degree 2
Max. Ambient Temperature 0 - 40°C
Relative Humidity 80%
IP Rating IP33
Dimensions (Assembled 7iE) 90 x 115 x 39 mm
Screen size 3.5in
Sensors Air & Floor (Ambient)
Sensor Type NTC10k 3m Long (Can Be Extended To 50m)
Operating Frequency 2401 - 2484MHz
Max. Radio-Frequency Power
Transmitted
20dBm
Installation Depth
Recommended: 50 mm Back Box
Minimum: 35mm Back Box
Compatibility
Electric, Hydronic Underoor Heating. Max.
16A (3680W)
Central Heating Systems
(Combi & system boilers with switch live,
230V AC input)
Er-P Class IV
Warranty 12 Years
Approvals BEAB
Hereby, Warmup plc, declares that the
radio equipment type 7iE-01-XX-YY is
in compliance with the RED Directive
2014/53/EU and Radio Equipment
Regulations 2017. The declarations of
conformity may be consulted by pressing
the CE or UKCA icon.
Instructions for Disposal
Do not dispose of the device with regular domestic waste! Electronic
equipment must be disposed of at local collection points for waste
electronic equipment in compliance with the Waste Electrical and
Electronic Equipment Directive.
Technical Specications
