5.3 Dimensions, output values, flue gas values
Model
K148/K148F
Registration
CE, 15a B-VG, VKF
External dimensions W x H x D (without lid)
See dimensional drawing 5.4
Height with top lids open
Height with top lids closed
Fire box W x D
234 x 421 mm
Fire box height min / max
280 / 470 mm
Hearth plate W x D
845 x 430 mm
Heating door opening W x H
180 x 200 mm
Oven W x H x D
460 x 360 x 420 mm
Flow and return connection
R1", backwards and sideways
Flue gas connection
150 mm ø
Water content in heating pocket
18.5 l
Operating pressure max
2.5 bar
Waterside pressure loss in heat pocket
At a flow of 0.75 m
3
/h:
1.5 m
3
/h:
4 mbar
8 mbar
Required delivery pressure at NHL
12 Pa
Flue gas temperature at flue gas connection at NHL
204 / 249 °C
Flue gas mass flow at NHL wood / brown coal
32,9 / 37,2 g/sec
Room heat capacity with coal for the room with favourable,
less favourable and unfavourable heating conditions ac-
cording to DIN 18893 / Tab. 2.
Continuous heating
Timed heating
165 / 95 / 65 m
3
114 / 68 / 46 m
3
Operating temperature at regulator setting 1 / 2 / 3
45 / 60 / 80°C
Weight gross / net
236 / 215 kg
CO (13% O
2
)
≤ 0,11 %
Dust (13% O
2
)
≤ 40 mg/m³
Efficiency (wood)
≥ 84 %
All information provided by the exhaust gas values are based on the EN 12815 under stationary labor
a-
tory conditions reserve the right to make changes which relate to technical advances and / or
to an
improvement in quality. We accept no liability for printing errors and changes which occur after printing
