Technical Manual
WDGA with CANopen Interface
8 - Setting-up the encoder
© Wachendorff Automation GmbH & Co. KG
50
Then the next segment is requested:
600h+ID
8
70h
01110000b
ccs=3, t=1
00h
00h
00h
08h
00h
00h
00h
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.23: Request next segment
The encoder answers with the next data segment:
580h+ID
8
1Dh
00011101b
scs=0, t=1,
n=6, c=1
data
x
x
x
x
x
x
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.24: Answer with next segment
Within this segment the encoder indicates that this was the last data segment and that
only the first data byte contained valid data. The 7 data bytes of the first segment and
the single valid data byte of the data bytes represent the 8 byte "High Precision Position
value" (object 6008h).
Segmented write access on an object:
Figure 8.6: Segmented-SDO write access
