Technical Manual
WDGA with IO-Link
4 - IO-Link
© Wachendorff Automation GmbH & Co. KG
20
4.5 Configuration and diagnostic parameters
Index
Subindex
Object Name
003A
Teach Select
RW
UINT8
Selection of which
channel is used for
teaching
003B
0
Teach Result
RO
UINT8
1
State
RO
0 = idle
1 = SP1 success
2 = SP2 success
3 = SP1, SP2 success
4 = wait for command
5 = busy
7 = error
2
Flag SP1 TP1
RO
Boolean
0 = inital or nOK
1 = OK
3
Flag SP1 TP2
RO
Boolean
see above.
4
Flag SP2 TP1
RO
Boolean
see above.
5
Flag SP2 TP2
RO
Boolean
see above.
003C
0
SSC1ParamPosition
RW
RecordT
1
HighLimit
RW
INT32
SP1 for SSC1
2
LowLimit
RW
INT32
SP2 for SSC2
003D
0
SSC1ConfigPosition
RW
RecordT
1
Logic
RW
UINT8
0 = high active
1 = low active
2
Mode
RW
UINT8
0 = deactivated
1 = single point
2 = window
3 = two point
3
Hysteresis
RW
INT32
0 = off
003E
0
SSC2ParamPosition
RW
RecordT
1
HighLimit
RW
UINT64
see above.
2
LowLimit
RW
UINT64
see above.
003F
0
SSC2ConfigPosition
RW
RecordT
1
Logic
RW
UINT8
see above.
2
Mode
RW
UINT8
see above.
3
Hysteresis
RW
INT32
see above.
400C
0
SSC1ParamVelocity
RW
RecordT
Note:
The Velocity SSC
channels are only
available in profile 4.2.2.
1
HighLimit
RW
INT32
see above.
2
LowLimit
RW
INT32
see above.
400D
0
SSC1ConfigVelocity
RW
RecordT
1
Logic
RW
UINT8
see above.
2
Mode
RW
UINT8
see above.
3
Hysteresis
RW
INT32
see above.
