Fig. 8
3. Remove hold thermostat.
4. Apply a small amount of thermal transfer
compound to the mating surface (disk side) of the
replacement thermostat.
A. Spread the compound completely and
evenly over the surface of the thermostat.
5. Reverse procedure to install and check steamer
for proper operation.
HIGH LIMIT THERMOSTAT
Disconnect the electrical power to
the machine and follow lockout /
tagout procedures.
Do not sharply bend and kink, or clamp down on the
capillary tube or damage may occur.
1. Remove right SIDE PANEL.
2. Disconnect lead wires from high limit.
Fig. 9
3. Remove thermostat from mounting bracket.
4. Remove screw and heat shield to access
capillary bulb.
Fig. 10
5. Loosen screws securing capillary bulb.
Fig. 11
6. Remove high limit thermostat.
C24EO SERIES ELECTRIC COUNTERTOP STEAMERS - REMOVAL AND REPLACEMENT OF PARTS
F25386 Rev. C (0421) Page 10 of 43
