REMOVAL AND REPLACEMENT OF PARTS
COVERS AND PANELS
Disconnect the electrical power to
the machine and follow lockout /
tagout procedures.
Cooking Compartment Side Panels
NOTE: Removal of left side panel is identical to the
procedure for the right side panel.
1. Remove the screws then remove the side panel
from the compartment.
Fig. 2
Cooking Compartment Flue Wrap
1. Remove left and right side panels from
compartment. Remove screws that secure flue
wrap.
Fig. 3
Cabinet Base Right Side Panel
1. Remove the screws then remove the right side
panel from the cabinet base.
Fig. 4
Cabinet Base Left Side Panel
1. Remove the screws then remove the left side
panel from the cabinet base.
C24GA AND C24DA SERIES CONVECTION STEAMER - REMOVAL AND REPLACEMENT OF PARTS
F35425 Rev. E (0119) Page 10 of 65
