IMPACT
®
4000
BUTTON NAVIGATION
ICON NAME FUNCTION
SETTINGS BUTTON
• Opens and Closes the Settings Menu
WIND BEARING CAPTURE BUTTON
• Opens and Closes the Wind Bearing Capture Screen
MEASURE BUTTON
• Power ON/OFF (Turn Impact ON/OFF)
• Takes Range
• Selects Menu Options
UP ARROW BUTTON
• Navigates Up in Menu Structure
• Increases Manually Inputted Values
DOWN ARROW BUTTON
• Navigates Down in Menu Structure
• Decreases Manually Inputted Values
LEFT ARROW BUTTON
• Navigates Back in Menu Structure
• Navigates Left when Manually Inputting Values
RIGHT ARROW BUTTON
• Navigates Deeper into the Menu Options
• Navigates Right when Manually Inputing Values
BACKLIGHT BUTTON
BACKLIGHTBACKLIGHTBACKLIGHT
• Turns ON/OFF Display Backlight
Note: To change the orientation of the Arrow Buttons on the Bluetooth
®
Remote, press and hold the button you wish to be
“Up” and the “Measure” button for three seconds until the light blinks green.
IMPACT
®
4000 BUTTONS
Measure Button
Right Arrow Button
Down Arrow Button
Up Arrow Button
Left Arrow Button
Settings Button
Wind Bearing
Capture Button
(W.B.C.)
Backlight Button
BLUETOOTH
®
REMOTE BUTTONS
Right Arrow Button
Measure Button
Up Arrow Button
Left Arrow Button
Down Arrow Button
