IMPACT
®
4000
NAVIGATING THE GEOBALLISTICS
®
APP
Across the top of the main screen of the GeoBallistics
®
App, there are four tabs: HUD, Chart, Map, and
Comp. See the App Settings Menu section on page 45 for more information regarding how to select which
tab is your default when first opening the GeoBallistics
®
App.
HUD Tab
From the HUD tab, you will see your ballistic solution
displayed in either MOA, MRAD, or inches based on
your preferences.
You will also see wind and shot information based on data
collected from either the Impact
®
4000, GeoBallistics
®
App,
a third-party weather meter, or selected airport data. Here you
may also click any buttons below each data point to capture
measurements from your mobile device. Wind speed can be
changed manually. Below is the Enter Range button. This
button can be used manually enter range from the app and
push it to the Impact
®
4000. Clicking either left or right arrow
next to this button will manually change the range value.
For Target, you may select the speed and direction of a
moving target to add this data to your ballistic solution.
On the bottom of the screen is Ballistic Data. This is based
on information from your selected rifle profile. See page 49
for more information about rifle profiles.
Chart Tab
From the Chart tab, you will see data for shot Angle, Direction,
and Range. Here you may also manually input this data to
change your ballistic solution.
Angle°
This displays your shot angle in degrees from the horizon
(ex: level = 0°, straight up = 90°).
Direction°
This displays shot direction in degrees from due north
(ex: north = 0°, east = 90°, south = 180°, west = 270°).
Range
This displays the ranged distance in either yards or meters.
You will also see a chart containing ballistic information
based on your selections. You can modify the range
increments and units on the App Settings page. The gray,
red, and yellow highlighted rows are GeoBallistics
®
Overlays.
See the GeoBallistics
®
Overlays section on page 55 for
more information.
You may export the chart data using the
button.
