1
There are two ways to set the output resistance (CR mode):
Mode one:
1. Press MODE and rotary the knob to select CR mode, press Enter to save.
2. Press Enter key to edit the resistor setting, Use the numeric 0-9 softkey to
set desired resistance. Press Enter key to save resistance setting, or turn
the knob to adjust directly to the set value.
3. Press ON/OFF key to output the setting resistance.
Mode two:
1. Press SHIFT+CV , at the same time, the user interface will switch into CR
mode.
2. Press Enter key to edit the resistor setting, Use the numeric 0-9 softkey to
set desired resistance. Press Enter key to save resistance setting, or turn
the knob to adjust directly to the set value.
3. Press ON/OFF key to output the setting resistance.
In constant resistance mode, the user can also set the following parameters.
Operation steps
1. Press CONF to enter PARAM.(PARAMETER SETUP)
2. Set I_LIM (maximum working current)
3. Set V_RANGE, I_RANGE (voltage/current range)
4. Set SR_RISE and SR_FALL (the rising/falling slope of resistance)
a) Fast b) Normal c) Slow
5. Set OVP, OCP, OPP
4.3.4 Constant Power Mode (CP)
When the user selects the SHIFT+ CC function key, the load enters constant
power mode. The electronic load will consume a constant power, as shown in
the figure below. If the input voltage increases, the input current will decrease.
The relationship between voltage and current is shown in the figure below.
