10 \
Control Panel - Input/Output
1. HD Port: Use this port to connect to a television. (HD cables not included)
2. USB 2.0 Port: Connect a USB drive to this port for music playback as well as displaying images
and videos. (See Page 18 for more information.) This port can also be used to charge the
wireless microphones using the USB 2.0 to Dual USB-C cable.
3. SD Card Slot: You can play back media stored on Micro-SD cards by inserting them in the
SD cardslot. You can navigate through the Micro-SD card with the U-Disk media browser.
Recommended format for Micro-SD cards is FAT32. See Page 18 for more details.
4. DC Input: Connector for the provided DC power supply.
5. Charge LED: This LED indicates the progress of charging the battery. Red indicates the
battery is being charged. Blue indicates that the battery has been fully charged. See Battery
Information Page for more details on the battery.
6. USB-C Port: You can connect a computer, phone or tablet to the USB-C port with the provided
Data Cable to use the WEDDING-SINGER as an audio interface. You can record the microphone
inputs as well as the music. (This port is for data only and does not provide charging power.)
7. Audio Input: 3.5mm stereo input for external audio sources.
8. Audio Output: 3.5mm stereo output. Use this to plug into an external powered speaker or
mixer. This outputs both music and microphone audio.
9. Condenser Mic Connection: This port supports computer condenser microphones like lapel
or headset mics that require power.
Please Note: The volume of this mic input cannot be changed with the control panel knobs or
the touch-screen display settings.
3
4
5
6 7
8
9
1 2
