12
Getting Connected
Connecting Mic/Line devices (CH 1-3)
The MIC/LINE inputs are for connecting microphones, instruments, or line-level pre-amp
outputs. The XLR-1/4” combo-jacks can accommodate both XLR and ¼” plugs. You can
connect either balanced or unbalanced cables. Once the devices are connected, the signals
can be customized using the individual channel strips, and further controlled using the DSP, EQ
and main system controls.
The cable used for these connections differ, with the plug being either XLR or ¼”.
If using a cable with an XLR plug, plug it into the outer XLR portion of the jack.
Cable needed: XLR to XLR
If using a cable with a ¼” plug, plug it in to the inner ¼” portion of the jack.
Cable needed: ¼” to XLR
NOTES:
If you are connecting a microphone that requires phantom power, make sure to set the +48V
button to ON.
If you are connecting a line-level pre-amp output, make sure to set the 30dB PAD button to
LINE.
XLR-M to XLR-F cable
or
0
L
R
1/4” - 1/4”
Mono Audio Cable
MIC,
INSTRUMENTS,
LINE-LEVEL PRE-AMP OUTPUTS
MOBILEMAN
