16
Front Panel
8. Eject Button ( ) - Opens and closes the disc tray.
NOTE: The Source Selector Switch must be set to DVD to open and close the disc tray.
9. Play/Pause Button ( ) - Plays a disc that is stopped or paused and pauses a disc that is playing.
10. Stop Button ( ) - Stops a disc that is playing.
11. Skip Buttons ( ) - Press (PREV) to jump to the previous track or chapter. Press (NEXT) to
jump to the next track or chapter.
12. Repeat Button - Cycles through the available repeat options: Repeat One, Repeat All, Repeat Off.
13. L/R Button - Cycles through the different multiplex CD+G output modes for canceling the vocals: MONO-
LEFT, MONO-RIGHT, STEREO. See the Operations section in this manual for detailed instructions on
canceling vocals on multiplex CD+G discs.
14. Display Button - Switches the display between time elapsed, and time remaining.
15. Channel Gain Controls -
Control the level of the gain on the individual microphone channels with each of
these knobs. Turn clockwise to increase, counter-clockwise to decrease.
16. Microphone Channel Inputs -
Use these four channel inputs to connect wired microphones or instruments
with a 1/4” plug.
NOTE: Plugging a wired mic or instrument into channel 1 will switch off wireless mic 1. Plugging a wired
mic or instrument into channel 2 will switch off wireless mic 2.
17. Echo Control - This controls the overall level for the ECHO effect on all four MIC INPUTS. This effect applies
slight delayed repetition(s) to the vocals providing for a rich, layered vocal sound. Rotate clockwise to
increase the amount of ECHO effect applied to the signal, and counter-clockwise to decrease.
18. Balance Control - This control adjusts the amount of sound that comes from the left or right channels. Turn
the knob clockwise to reduce the volume of the left channel. Turn the knob counter-clockwise to reduce the
volume of the right channel.
19. Mp3 Input - Connect an Mp3 player or any output device to the 1/8” audio input.
20. Master Volume Control - Control the volume output of all audio with the MASTER VOLUME Control. Turn
clockwise to increase volume, counter-clockwise to decrease.
Descriptions and Functions
