15
Front Panel
1. Graphic Equalizer Control - This GRAPHIC EQ is used to BOOST and/or CUT particular frequencies. Each slide
fader processes a particular frequency range indicated by the number below it. Frequencies from 100Hz - 330Hz
constitute the very low to low range. Frequencies from 330Hz to 1kHz are the mid-range and frequencies
from 1kHz to 10kHz make up the high to very high range. To adjust, slide the fader up to boost the frequency
presence and down to cut the frequency presence.
NOTE: This control only changes the output of the DVD-SOUNDMAN’s on-board speakers. It does not affect the
output of the stereo RCA or digital audio outputs on the rear panel.
2. Disc Tray -
Press the EJECT button ( ) to open the DISC tray. Carefully set your disc onto the tray and press the
EJECT button ( ) again to close tray. Never push or force the tray closed manually.
NOTE: The Source Selector Switch must be set to DVD to open and close the disc tray.
3. Remote Control Sensor - Receives signals from the remote control. For best results, aim the remote control
directly at this sensor.
4. Power Button - Use this switch to power the DVD SOUNDMAN ON or OFF.
5. Source Selector Switch -
Use this switch to select which audio source you want to use:
AUX: The RCA audio inputs on the back panel.
DVD: The disc player.
Mp3: The 1/8” audio input jack on the front panel.
6. VFD Display - Displays track, playback and setting information.
7. Key Controller - Adjusts the musical key of music to fit the singer’s vocal range. Press the DOWN (-) button to
lower the musical key. 0 - resets the music to the original or ‘natural’ key. Press the UP (+) button to raise the
musical key.
NOTE: Digital Key Control changes the key of music but will not affect the microphone vocals.
Descriptions and Functions
