13
Getting Connected
Power
Using the supplied power cable, connect one end to an AC
power receptacle, and connect the other end to the power
jack on the Casaman’s back panel.
NOTE: The Casaman is power configuration is factory set.
For customers on a 220V power grid, make sure that your
Casaman has been configured for 220V use. You can check
this on the top panel power designation. If it is not configured
for 220V use, contact VocoPro tech support at
+1(909) 593-8893 or techsupport@vocopro.com.
Audio
You can connect source audio to the RCA jacks on the rear panel or to the 1/8” jack on the front panel.
The ¼” input jacks on the rear panel accept both unbalanced TS and balanced TRS cables. If you are unsure whether
to go balanced or unbalanced, here are a few general guidelines: 1) home stereo equipment typically uses unbalanced
audio connections, while professional audio equipment uses balanced, and 2) if your source audio cable is less than 10 ft,
unbalanced is ne; if it is more than 10 ft, go balanced.
The front-mounted 1/8” offers a convenient way to connect audio from devices such as smartphones, tablets, computers, or
other devices with an 1/8” audio output. This audio input is pre-amplied, so that audio signal will be louder from this input
than the RCA inputs on the rear panel.
CASAMAN
Designed in California
Assembled in Taiwan
Stereo Music
Expansion Port
Wireless Microphone Port
by
DELAYMIC 1
MIC MASTER
PEAK
PEAK
USB MP3
POWER
AUX
MIC 2 REPEAT MID
BASS
CASAMAN
ECHOREVERB
HEADPHONE
STEREO
MP3
Designed in California
Assembled in Taiwan
Stereo Music
Expansion Port
Wireless Microphone Port
by
MPX
TREBLE
MUSIC
DELAYMIC 1
MIC MASTER
PEAK
PEAK
USB MP3
POWER
AUX
MIC 2 REPEAT MID
BASS
CASAMAN
ECHOREVERB
HEADPHONE
STEREO
MP3
Designed in California
Assembled in Taiwan
Stereo Music
Expansion Port
Wireless Microphone Port
by
MPX
TREBLE
MUSIC
RCA cables
1/8” Stereo Audio Cable
1/8” cable
TS unbalanced TRS balanced
DELAYMIC 1
MIC MASTER
PEAK
PEAK
USB MP3
POWER
AUX
MIC 2 REPEAT MID
BASS
CASAMAN
ECHOREVERB
HEADPHONE
STEREO
MP3
Designed in California
Assembled in Taiwan
Stereo Music
Expansion Port
Wireless Microphone Port
by
MPX
TREBLE
MUSIC
