HMI ADDRESS FOR BMS sets the HMI address code for BMS.(only valid for master controller)

The STOP BIT of wired controller and upper computer software should be the same to ensure the reliability of data

transformation.

8 Operation parameter

MENU > OPERATION PARAMETER

This menu is for installer or service engineer reviewing the operation parameters. There are nine pages for the operating

parameter as following

Figure 3-9.1: Operation parameter

OPERATION PARAMETER

#01

OPERATE MODE COOL

ADDRESS

SV1 STATE ON

ONLINE UNITS NUMBER 1

SV2 STATE OFF

SV3 STATE OFF

PUMP_I ON

1/9

OPERATION PARAMETER

#01

PUMP-C OFF

ADDRESS

PUMP-S OFF

PUMP-O OFF

PUMP-D OFF

PIPE BACKUP HEATER OFF

TANK BACKUP HEATER ON

2/9

OPERATION PARAMETER

#01

T1 LEAVING WATER TEMP. 35°C

ADDRESS

WATER FLOW 1.72m

GAS BOILER OFF

HEAT PUMP CAPACTIY 11.52kW

POWER CONSUM. 1000kWh

Ta ROOM TEMP 25°C

3/9

OPERATION PARAMETER

#01

Tw2 CIRCUIT2 WATER TEMP. 35°C

ADDRESS

TIS’ C1 CLIMATE CURVE TEMP. 35°C

T5 WATER TANK TEMP. 53°C

TIS2’ C2 CLIMATE CURVE TEMP. 35°C

TW_O PLATE W-OUTLET TEMP. 35°C

TW_I PLATE W-OUTLET TEMP. 30°C

4/9

OPERATION PARAMETER

#01

Tbt2 BUFFERTANK_LOW TEMP. 35°C

ADDRESS

IDU SOFTWARE 01-09-2019V01

Tbt1 BUFFERTANK_UP TEMP. 35°C

5/9

Tsolar 25°C

OPERATION PARAMETER

#01

COMP.CURRENT 12A

ADDRESS

COMP.FREQENCY 24Hz

ODU MODEL 6kW

COMP.RUN TIME 54 MIN

COMP.TOTAL RUN TIME 1000Hrs

EXPANSION VALVE 200P

6/9

OPERATION PARAMETER #01

IDU TARGET FREQUENCY 46Hz

ADDRESS

FREQUENCY LIMITED TYPE 5

FAN SPEED 600R/MIN

SUPPLY VOLTAGE 230V

DC GENERATRIX VOLTAGE 420V

DC GENERATRIX CURRENT 18A

7/9

OPERATION PARAMETER #01

TW_I PLATE W-INLET TEMP. 30°C

ADDRESS

T2 PLATE F-OUT TEMP. 35°C

TW_O PLATE W-OUTLET TEMP. 35°C

T2B PLATE F-IN TEMP. 35°C

Th COMP. SUCTION TEMP. 5°C

Tp COMP. DISCHARGE TEMP. 75°C

8/9

OPERATION PARAMETER #01

T4 OUTDOOR AIR TEMP. 5°C

ADDRESS

TF MODULE TEMP. 55°C

T3 OUTDOOR EXCHARGE TEMP. 5°C

P1 COMP. PRESSURE 2300kPa

ODU SOFTWARE 01-09-2018V01

HMI SOFTWARE 01-09-2018V01

9/9
