7.3 FOR SERVICEMAN Menu

FOR SERVICEMAN allows installers to input the system configuration and set

the system parameters. To enter FOR SERVICEMAN, go to MENU > FOR

SERVICEMAN.

Enter the password, using ◄ ► to navigate between digits and using ▼ ▲ to

adjust the numerical values, and then press OK. The password is 234. Refer to

Figure 3-7.2

Then the following pages will be displayed after putting the password. Refer

to Figure 3-7.3

7.4 DHW MODE SETTING Menu

7.4.1 DHW MODE SETTING menu overview

MENU > FOR SERVICEMAN > DHW MODE SETTING

Figure 3-7.4: DHW MODE SETTING menu

In DHW MODE SETTING the following parameters should be set.

DHW MODE enables or disables DHW mode. For installations with DHW tanks, select YES to enable DHW mode. For

installations without DHW tanks, select NON to disable DHW mode.

DISINFECT sets whether or not the disinfection operation is performed.

DHW PRIORITY sets whether domestic hot water heating or space heating/cooling takes priority. If NON is selected in the

DHW PRIORITY mode, when it is available and the space heating/cooling is OFF, the heat pump will heat the water as

required. If space heating/cooling is ON, the water will be heated as required when the immersion heater is unavailable.

Only when the space heating/cooling is OFF will the heat pump operate to heat domestic water.

1 DHW MODE SETTING

YES

NON

ADJUST

1.1 DHW MODE

1.2 DISINFECT

1.3 DHW PRIORITY

1.4 DHW PUMP_D

1.5 DHW PRIORITY TIME SET

1/5

5 °C

10°C

43°C

-10°C

5 MIN

1 DHW MODE SETTING

1.6 dT5_ON

1.7 dT1S5

1.8 T4DHWMAX

1.9 T4DHWMIN

1.10 t_INTERVAL_DHW

2/5

ADJUST

5 °C

30 MIN

65°C

15MIN

1 DHW MODE SETTING

1.11 dT5_TBH_OFF

1.12 T4_TBH_ON

1.13 t_TBH_DELAY

1.14 T5S_DISINFECT

1.15 t_DI_HIGHTEMP.

ADJUST

3/5

210 MIN

30 MIN

120 MIN

YES

5 MIN

1 DHW MODE SETTING

1.16 t_DI_MAX

1.17 t_DHWHP_RESTRICT

1.18 t_DHWHP_MAX

1.19 PUMP_D TIMER

1.20 PUMP_D RUNNING TIME

4/5

ADJUST

NON

1 DHW MODE SETTING

1.21 PUMP_D DISINFECT RUN

5/5

ADJUST

Figure 3-7.2: FOR SERVICEMAN password screen

Figure 3-7.3: FOR SERVICEMAN menu

Please input password:

2 3 4

ENTER

FOR SERVICEMAN

ADJUST

ENTER

FOR SERVICEMAN

1. DHW MODE SETTING

2. COOL MODE SETTING

3. HEAT MODE SETTING

4. AUTO MODE SETTING

5. TEMP.TYPE SETTING

6. ROOM THERMOSTAT

1/3

7. OTHER HEATING SOURCE

8. HOLIDAY AWAY SETTINGTING

9. SERVICE CALL SETTING

10. RESTORE FACTORY SETTINGS

11. TEST RU N

12. SPECIAL FUNCTION

ENTER

FOR SERVICEMAN 2/3

ENTER

FOR SERVICEMAN

13. AUTO RESTART

14. POWER INPUT LIMITATION

15. INPUT DEFINE

16. CASCADE SET

17. HMI ADDRESS SET

3/3
