ENG VIVAX

102

10 USB function guidelines

10.1 Parameters setting transfer between wired controllers

Installer can quickly copy the wired controller parameter settings from unit A to unit B via USB disk, which save the

time of on-site installation. Steps are as follows:

Step 1:

Plug U disk into the port of hydronic PCB of A unit.

“USb” appears on digital display

Wired controller interface automatically changes

Step 2:

Select “READ SET PARAMETER” and press “OK” button then rate of progress will appear. When the process is finished,

“SUCCESS” appears below and an EXCEL file which can not be seen in the wired controller interface but users can find it on

computer will be generated inside the USB disk.

Select “READ SET PARAMETER”

Finished

EXCEL generated

After that, if parameter correction is needed, please connect the USB with computer and open the EXCEL file to change

parameters and then save it. Please do not change the file name or format. Parameters are not allowed for

non-professionals to change and Midea recommends to use the wired controller to change the parameters.

Step 3:

Plug USB disk into the port of hydronic PCB of B unit and select “WRITE SET PARAMETER” then rate of progress will appear.

When the process is finished, “SUCCESS” appears below.

Select “WRITE SET PARAMETER”

Finished

USB FUNCTION

WRITE SET PARAMETER

CONFIRM

READ SET PARAMETER

USB FUNCTION

WRITE SET PARAMETER

CONFIRM

READ SET PARAMETER 63%

USB FUNCTION

WRITE SET PARAMETER

CONFIRM SUCCESS

READ SET PARAMETER

USB port
