6680
5/40
GB
POWER SUPPLY TERMINALS SUGGESTED CONDUCTOR COLOUR
(Ref. Cable type 0061/001..., 0061/003...)
1: Interphone receiver SKY BLUE
2: Interphone microphone WHITE
3: Common interphone line PINK
- : Negative terminal of monitor supply voltage BLACK SECT. 1mm
+: Positive terminal of 18V D.C. 0.8A monitor supply RED SECT. 1mm
S: Control of lock relay BROWN
M: Block of coaxial cable shield
V1-V2: Block of video signal (on coax cable) COAXIAL CABLE
6: Common interphone line for speech unit PINK
7: Speech unit microphone WHITE
8: Speech unit loudspeaker SKY BLUE
+T: 13V D.C. 0.3A camera supply voltage ORANGE
- : Negative line for camera supply voltage BLACK SECT. 1mm
AM: Short-circuited to negative line, blocks monitor activation
0: 0V (with reference to terminal 16) BROWN
15: 15V rectified voltage (selector in “A” position).or 250mA RED SECT. 1mm
alternated (selector in “B” position on continuous
operation)
S1: Wiring to electric lock BLUE SECT. 1mm
C1: Speech unit electronic call GREEN
C2: Electronic call outside apartment landing call WHITE/GREEN
AU: Self-start
CONNECTIONS TO
MONITORS +
INTERPHONES
CONNECTION TO CA-
MERA ENTRANCE
PANEL
TERMINALS FOR MONITOR TYPE 6620, 662A, 6720, 7200
1: Interphone receiver
2: Interphone microphone
3: Common audio line
4: Button for auxiliary services (related to terminal 5)
5: Power supply negative
6: Power supply positive (minimum input voltage 15V D.C.)
7: Second auxiliary function or self-start (its operation is controlled by the microswitch placed on the monitor rear side).
8: Call from entrance panel
9: Lock push-button
10: 12V D.C. output for video distributor
11: Landing call
12: Push-button for the audio activation (or self-start with switch in “A” position)
13:
Green LED supply voltage (18V D.C. (max) positive voltage imput)
V: For systems with coaxial cable, input for connection of the 75 Ohm video cable.
M: Ground for terminals V.
NOTE: Monitor type 6620, 6720, 7200 dispose on the rear of a microswitch for the switching of the "auxiliary (position
A)/self-start (position B)" function of push-button .
Monitor type 662A dispose of a micro-switch on the bottom of the basis for the switching of the "auxiliary" function (lower
position) /self-start (upper position) of push-button , and all monitor dispose of the colour adjustment.
PROGRAMMING OF THE CONVERSATION PRIVACY
FOR MONITOR SERIES 6600, 7200
The "Conversation privacy" function can be obtained by pressing both push-buttons " " for 3 seconds at the same time; when
the red led flashes press the push-button. The "without conversation privacy" function can be obtained as indicated above,
but using both " " push-buttons.
