BUILDING AUTOMATION

General - Technical Data

The function is summarized as follows:

- Supports three valve control types

- Monitor the control values on the bus to send fault status

- Valve characteristic curve correction (only for continuous valves)

- Automatic valve adjustment (for continuous valves only)

- Prohibit/enable heating or refrigerating valves

- Valve position status feedback or query

- Manual or automatic cleaning of the valve, sending the cleaning status

Programmers are able to use the Engineering Tool Software ETS (ETS4 version or above) with a .knxprod file to allocate the physical address and set the parameters.

To make sure that all the programmable functions are used correctly, you must check the connection of the loads before use and note technical characteristic of loading

equipment, particularly shutter driver, they refer more technical characteristics, some characteristics are inherent, if not properly set them, it is likely to cause the load device

damage or not operating correctly.

2. Technical Data

Power Supply

Operation voltage 21~30V DC, via the KNX bus

Current consumption, bus < 9 mA

Connection KNX Via bus connection terminals,Ø 0.8 mm

Outputs Screw terminals

Wire Range 0.2-4mm

, Torque 0.8N-m

Operation / Display Programming LED and button For assignment of the physical address

Green LED ﬂashing Indicate the application layer running normally

Manual operation button Switch output

Output LED Indicating output status

Manual / auto button Switch manual/automatic mode

Manual / automatic LED Indicates manual/auto mode status

Protection IP 20, EN 60 529

Temperature range Operation -5°C...+45°C

Storage -25°C...+55°C

Transport -25°C...+70°C

Ambient conditions Rel. humidity < 93%, except dewing

Design Modular installation device (MDRC)

Housing/color Plastic, beige

Installation On 35mm DIN-Rail, To EN 60 715

Dimension/Weight 216 mm × 90 mm × 64 mm / 0.6 kg

Output Max. 16 Fold Switch Outputs / 8 Fold Shutter AC

Outputs / 4 Fold Shutter DC Outputs / 4 Fold Fan

Coil Outputs / 4 Fold Valve Outputs

Each Output can be conﬁgured separately

Un Rated Voltage 230/277V AC(50/60Hz),30V DC

Rated Current/capa 10A/105uF(LED Max. Load 200W)

Inrush current 300A/2ms

Max. Switching Current 20A/250V AC

Mechanical life > 1 x 10

Electrical life > 5 x10

Min. applicable load (reference value) 100mA 5V DC

Note: For the relay parameters, the above load is only for a single lamp. When multiple lamps are connected in parallel, the load can be reduced. Although the

power is constant, the instantaneous inrush current will increase, which will easily melt the relay contacts. Therefore, in normal use, based on the measured cur-

rent, the measured maximum inrush current must be within the allowable range.

Application program:

Application program Max. number of communication objects Max. number of group addresses Max. number of associations

Multifunctional Actuator, 16-Fold 532 1000

1000
