BUILDING AUTOMATION

1. General

The Multifunctional Actuator is a multi-output module, integrating multiple output functions, including switch output, curtain DC/AC output, fan output and valve output.

You can configure the functions of the module according to your requirement, such as a part of the output for controlling the switch, a part of the output for controlling the

curtain, and a part of the output for controlling the fan.

With 16 outputs for selection, the output of different output channels is different.

For details, please refer to the technical chapter. One relay in the device represents one output, and some functions may require multiple outputs. For example, one curtain

AC output needs to occupy two relay outputs, one relay is used to control Positive rotation, and one is used to control reverse rotation, and the common switch The output

needs to occupy one relay output. Therefore, in the engineering application process, the product is selected according to actual needs. And with manual operation buttons

on the top of the product, it is more convenient to cope with engineering debugging.

The Multifunctional Actuator is a modular mounting device. For easy installation in the distribution box, it can be mounted on a 35 mm D-rail according to EN 60 715. The

device is screwed to the electrical connection and the bus connection is directly connected via KNX Terminal connections, system power supply does not require an ad-

ditional supply voltage other than the bus.

This manual provides detailed technical information about the Multifunctional Actuator for users as well as assembly and programming details, and explains how to use the

device by the application examples.

The function of the Multifunctional Actuator is summarized as follows:

• Switch output, which can connect some electrical loads, such as lighting, sockets and heating control.

The module offers the following functions:

- Switch

- Time function: on/off delay

- Time function: flashing switch, for lamps of aging test

- Time function: staircase lighting, for switch on the staircase lighting and after the duration time the lighting can be turned off automatically. It is better if the

function is used together with motion detector.

- Provide 8 scenes, recall and storing via a 1byte object

- Logic operation: AND, OR, XOR, GATE function, up to three logic inputs

- Status response, for know the current output state in the visualization

- Forced operation, two data types: 1bit/2bit, for force action on or off, with the highest priority

- Heating valve control

- Set the relay contact position after bus voltage recovery

- Set the relay contact position after bus voltage failure

- Manual switch outputs

• Shutter AC/DC output, which can connect with motor blinds, awnings, roller blinds, vertical blind, etc. There are 8 outputs with 230V AC 1000W motor or dry contact

controlling motor or 4-channel DC control mode (DC motor control type). The output contacts for the directions UP and DOWN. The pause on change in direction can be

set via the parameters. The curtains AC and DC are wired differently. The curtain AC occupies two relays per channel, and the curtain DC occupies four relays per channel.

For the specific wiring method, please refer to the connection diagram in the third chapter, but their functions are similar.

The specific functions are summarized as follows:

- Movement UP/DOWN

- Stop/Louvre adjustment

- Move to position 0……100%

- Adjustment Louvre to position 0……100%(only “Venetian Blind” working mode)

- Set 8 scenes, store or recall via a 1byte object

- Automatic sun protection

- Safety function

- Status response, query and reply the current shutter/blind position and operation mode to the bus, thereby indicating the status in the visualization device

- Two working mode :Venetian Blind and Shutter

• Fan Drive Control, can be connected to a single-phase fan, supports up to 3 levels of fan speed adjustment, the output contacts are the same as the switch output.

The function is summarized as follows:

- Support the fan with 1-2-3 level fan speed

- The fan has two operating modes: step switch and steering switch

- Forced operation: The fan speed is only allowed within the allowed fan speed range, with the highest priority

- Automatic operation: Automatically run the fan speed according to the control value. The control value is obtained by the sensing device on the bus, and the

minimum running time of the fan speed can be set.

- Normal operation: manually control the operation of the fan, such as through the operation panel, etc.

- Fan with multi-level fan speed can set start-up characteristics

- Single-level fan speed fan can set on/off delay or minimum running time

- Status feedback, such as automatic operation status, fan switching status, fan speed, etc.

- Operational control of bus power-up or power-down behavior

• Valve control, can be used to connect 2 control or 4 control coil system, cooling valve and heating valve respectively use separate relay output, there are three types of

control: continuous (3 point, open and close), PWM switch (continuous, PWM) and 2-point switch type (2 state-ON/OFF).

The continuous type controls the opening of the valve according to the control value of the valve. It can completely open or close the valve, and can also stop the valve in

an intermediate position. This type of control is suitable for driving three-wire valves.

The PWM switch type can only make the valve fully open or completely closed. The valve is cyclically operated according to the control value (1byte) and PWM cycle. The

valve switch is divided into normally open or normally closed. This control type is suitable for driving two-wire system. Valve.

The 2-point switch type is similar to the PWM switch type, and can only be fully opened or completely closed. The difference is that it is directly turned on or off according

to the control value (1 bit) on the bus. It is usually suitable for the case where the switch valve is controlled according to the temperature difference. And suitable for driving

two-wire valves.

General
