Viking | RVL Steam Oven | MVSOC6301
EN-6
Installation Preparation
P I
Installers, it is your responsibility to...
• Comply with installation specifications and
dimensions.
• Properly install the unit.
• Remove any molding or decorative panels that
prevent the unit from being serviced.
• Make sure that you have the necessary tools and
materials on hand to install the unit.
• Provide a properly grounded electrical outlet.
• Any installation not matching the specifications
discussed in these instructions will void the
manufacturer’s warranty.
Included Accessories and Parts
• Wire Shelf
• 4 Mounting Screws
• Perforated Tray
• Meat Probe
• Water Tank
Remove Packaging & Accessories Before Installing
• Failure to remove packaging materials could result in damage to the appliance.
• Remove the steam oven from the packaging. Recycle the materials that can be reused. Dispose of packaging
materials in accordance with local regulations on waste disposal. Don't leave packaging around for children to
play in.
• Inspect the steam oven for any signs of damage on the exterior, the internal oven cavity, and the door seals. Do
not install the steam oven if it has been damaged. If the product is damaged, contact your local dealer.
• Open the steam oven and remove all packing parts, literature pack and accessories from the interior.
• Only remove protective film and labels on the outer door, control panel, and handle once installation
is complete.
• Locate the Parts package containing mounting screws.
Tools You May Need
• 1/8" Drill Bit and Electric Drill
• Tape measure and straight
edge or ruler
• Pencil
• Phillips screwdriver
• Level
• Wire cutters and wire stripper
• Hand or saber saw
• 1” (2,5 cm) Hole saw
• Safety gloves and goggles
• Volt meter (0-250VAC)
Design Information
The steam oven may be installed in a cabinet alone, above or below other appliances such as a warming drawer,
wall oven, speed cook oven, or another steam oven. The steam oven may also be installed side by side, below a
countertop, or below specified cooktops. When installing this unit directly below other units, only install with Viking
Range, LLC built-in products.
IMPORTANT: Always refer to individual installation instruction packed with each product for specific requirements.
Prepare Installation Location
• It is the responsibility of the installer to comply with local codes. If no local codes are applicable, wire in
accordance with the National Electrical Code, ANSI/NFPA-70 – latest edition.
• Ground unit per applicable electrical codes.
• The steam oven should be located away from strong drafts, but in a convenient location in the kitchen.
• It is recommended that 3/4” or larger material be utilized to create a support platform for this appliance.
• BE SURE that support for this appliance is perpendicular to the front facing of the wall or cabinet before you
perform the installation.
