4/28
Operating
Temperature
32 - 104°F / 0 - 40°C
Storage
Temperature -4 - 140°F / -20 - 60°C
Relative
Humidity 20 - 90% RH (no-condensing)
5. Operation Controls and Functions
5.1 Front Panel
No.
Name
Function Description
1 Power button
▪
Short press this button to power on the device.
▪
Long press this button for 1 seconds to enter the standby
mode.
2 Power LED
The Power LED will light in green when the product is
powered on, and red when the product is on standby.
3 Input 1-4 LEDs
Input signal indicator lights.
In single screen display mode, when the HDMI OUTPUT
port outputs the signal from the HD 1/2/3/4 port, the
corresponding green LED will be on.
In multiview mode, all input signal LEDs will light in green.
4 AUTO LED
In single screen display mode, when the device is set to
AUTO mode, the AUTO LED will light in green, and HDMI
is identified automatically, that is, when the currently
displayed source signal is disconnected, the switcher will
automatically identify the next connected HDMI input port.
5 IR Window
IR signal receiving window.
Seamless UHD Video & USB3.0 KVM Switcher
With Multiviewer Control
