6. Rack Mounting Instruction
① Power on or Standby: Press this button to power on the
switcher or set it to standby mode.
② VIDEO buttons:
HD 1/2/3/4: Press these buttons to select input source
in single screen display mode, and the corresponding
input LED on the front panel will light in green.
: In single screen display mode, press this button to
switch to the previous input;
In multiview mode, press this button to switch to the
HOST of the previous window.
: In single screen display mode, press this button to
switch to the next input;
In multiview mode, press this button to switch to the
HOST of the next window.
: Multiview display mode switching button.
▪ Short press this button to circularly select: Single - PIP - PBP (1) -
PBP (2) - Triple (1) - Triple (2) - Quad (1) - Quad (2) - Single.
▪ Long press this button for 3 seconds to select the aspect ratio (16:9/Full)
for PBP (1) / PBP (2) / Triple (1) / Triple (2) / Quad (1) / Quad (2).
Res : Output resolution switching button.
▪ Short press the RES button to circularly switch the output resolution of
the HDMI OUTPUT port (Please refer to the output resolution list of “8.
Video & Audio”).
▪ Long press the RES button for 3 seconds to switch the output resolution
to 720P60.
③ MENU buttons:
MENU, EXIT, LEFT, RIGHT, UP, DOWN, OK: OSD Menu navigation buttons.
④ AUDIO buttons:
A-IN: Press this button to pop up the audio channel selection OSD, then press
the UP / DOWN button to select the audio output channel. (The output audio
follows the video source by default.)
Mute: Press this button to mute / unmute the audio.
VOL-, VOL+: Press these buttons to increase / decrease the audio output
volume.
