6. TCP/IP Control Command
The product supports TCP/IP command control. Connect the LAN port of the product to a PC,
then open a TCP/IP Command tool on PC to send TCP/IP commands to control the product.
The TCP/IP command list about the product is shown as below.
TCP/IP Commands
Service Port Number: 3433
The control command ends with “\n”, and no symbols in the form of "\n" can appear in the middle of
the command.
Channel number: 0~7, corresponding to the Mic/Line input channels 1~8 of the device.
Channel number: 96 indicates AM, which is the audio signal after auto mixer process.
Channel number: 97 indicates AFC, which is the audio signal processed by the AFC module.
Channel number: 98 indicates AEC, which is the audio signal processed by the AEC module.
Channel number: 99 indicates ANS, which is the audio signal processed by the ANS module.
Channel number: 100~107, corresponding to the analog output channels 1~8 of the device.
Channel number: 196 indicates the reference signal of AEC.
HChanl (Channel Command)
<HChanl></HChanl>
It is used to control the mute, phantom power, inversion and analog gain adjustment of the channel.
Field
no: Channel number, no=0~7 or 100~107
.
mu: Mute switch, mu="0" (unmute), mu="1" (mute).
phpow: Phantom power switch，phpow="0" (phantom power on), phpow="1" (phantom
power off).
invrt: Invert function switch, invrt ="0"(non-invert)，invrt ="1" (invert).
><: Gain setting. The value range is [-12, +40]dB.
Example
<HChanl no="0" mu="0" phpow="1" invrt="1">1</HChanl>
Indicates: Channel 0, unmute, phantom power on, invert, analog gain amplified 1dB.
HNg (Signal Generator)
<HNg></HNg>
It is used to generate white noise, pink noise and sinusoidal signal of arbitrary frequency.
Field
no: Channel number, no=0~7.
opt: Enable/disable switch, opt="0" (disable), opt="1" (enable).
type: Signal type, type="0" (white noise), type="1" (pink noise), type="2" (sinusoidal signal)
frq: The frequency of sinusoidal signal, frq =20~20000Hz.
><:
Level value. The value range is [- 60, 0]dB.
Example
<HNg no="3" opt="1" type="2" frq="1000">-24</HNg>
Indicates: Enable the signal generator function module of the input channel 3, and
generate
1000Hz sinusoidal signal with -24dB.
HLevCtrl (Level Control)
<HLevCtrl></HLevCtrl>
It is used to control the digital level of the corresponding audio channel.
Field
no: Channel number, no=0~7 or 100~107.
><: Level value. The value range is [-100, 12]dB.
Example
<HLevCtrl no="5">0</HLevCtrl>
Indicates: Set the level value of the input channel 5 to be 0dB.
