Instruction manual - English - EN
11MNVCHPVHPOE_2222_EN
VERSO HIPOE IPM AVAILABLE MODELS AND FEATURES
Operating
temperature
Injector Camera Demisting Hea-
ting system
Illuminator Heater Fan with double
air filter
From -10°C (14°F)
up to +60°C
(140°F)
PoE class 3 (13W) PoE max. class
2 (7W)
√
– –
√
Hi-PoE class 4
(25W)
PoE max. class 3
(13W)
√ √
–
√
From -10°C (14°F)
up to +60°C
(140°F)
PoE class 3 (13W) PoE max. class
2 (7W)
√
– – –
Hi-PoE class 4
(25W)
PoE max. class 3
(13W)
√ √
– –
From -30°C (-22°F
) up to +60°C
(140°F)
Hi-PoE class 4
(25W)
PoE max. class 3
(13W)
√
–
√
–
Tab. 3
8 Switching on
The automatic pre-heating (De-Ice) process
could be started whenever the device is
switched on and the ambient temperature
is below 0°C (+32°F). The procedure is
necessary to guarantee correct operation
of the devices even at low temperatures.
The duration ranges depending on
environmental conditions (from 60 minutes
up to 120 minutes).
During the lighting phase the device reads the
status of the dip switch and automatically detects
all the connected options for the correct energy
management of the housing.
The LEDs shown in the figure allow to check the
product's operating status.
Fig. 14
Refer to the table to identify the operating status.
