EN - English - Instructions manual
6 MNVCHEEPOE_2222_EN
6.3 Fixing the sunshield
It’s possible to fix the sunshield to the housing using
screws, washers and spacers provided.
Fig. 4
7 Installation
7.1 Fixing of housing to support
Apply a thread-locker on the holes of the
screws (Loctite 243®).
Fix the housing to the support using the supplied
screws.
Fig. 5 Fixing on support with external cable passage.
Fig. 6 Fixing on support with internal cable passage.
7.2 How to install the camera
Fasten the camera with the 1/4" screw (03). To
position the camera and lens correctly, if necessary,
use the supplied spacers. (04).
02
03
01
Fig. 7
Fasten down the adjustable slide in the correct
position using the appropriate screws.
Fig. 8
