Instruction manual - English - EN
11MNVCNXW_2222_EN
10.3 Housing's window
Usable diameter: 95mm (3.7in)
Tempered extra clear glass
• Thick: 6mm (0.24in)
• Operating temperature: 260°C (500°F) max,
thermal gradient 108°C (226.4°F) max
Quartz glass
• Thick: 6mm (0.24in)
• Operating temperature: 400°C (752°F) max,
thermal gradient 220°C (428°F) max
IR-proof glass
• Thick: 6.6mm (0.3in)
• Operating temperature: 260°C (500°F) max,
thermal gradient 108°C (226.4°F) max
10.4 Electrical
Camera power supply
IN from 100Vac up to 240Vac, 50/60Hz - OUT 12Vdc,
1.25A
IN 230Vac, 50/60Hz - OUT 24Vac, 400mA
10.5 Environment
For indoors and outdoors installation
Maximum working temperature (with water cooling):
• with tempered glass 260°C (500°F) max
• with quartz glass 400°C (752°F) max
• with IR-proof glass 260°C (500°F) max
Relative humidity: from 5% up to 95%
10.6 Certifications
Electrical safety (CE): EN60065, EN62368-1
Electromagnetic compatibility (CE): EN50130-4,
EN61000-6-3
IP protection degree: EN60529, IP66/IP67
EAC certification
