EN - English - Instruction manual
12 MNVCIRN_2222_EN
9.4 Illuminators
LED SMD
GEKO IRN BEAM PATTERN AND ACHIEVABLE DISTANCES FOR ONE
ILLUMINATOR
Horizontal
and vertical
beam pat-
terns
Maximum distance
850nm 940nm White light
10˚ 240m (787ft) 140m (460ft) –
30˚ 130m (427ft) 80m (262ft) 120m (393ft)¹
60˚ 80m (262ft) 60m (197ft) 90m (295ft)¹
Tab. 4 The distances and the performance depend on the
camera/lens used and on the environmental light
conditions.
¹ Achievable distances with camera in Day mode
(colour image)
9.5 Environment
For indoors and outdoors installation
Operating temperature: from -40°C (-40°F) up to
+60°C (140°F)
9.6 Certifications
Electrical safety (CE): EN60950-1, IEC60950-1,
EN62368-1, IEC62368-1
Electromagnetic compatibility (CE): EN50130-4,
EN55032 (Class A), EN61000-6-4
Electromagnetic compatibility (North America): FCC
part 15 (Class A), ICES-003 (Class A)
Outdoor installation (CE): EN60950-22, IEC60950-22
Photobiological safety (CE): EN62471, IEC62471
IP protection degree (EN60529): IP66, IP67
IK protection degree : IK10
UL certification (UL60950-1, CAN/CSA C22.2 No.
60950-1-07): cULus Listed
Level of protection Type (UL50E): 4X
EAC certification
Restriction of Hazardous Substances (RoHS), Directive
2011/65/EU
Waste Electrical and Electronic Equipment (WEEE),
Directive 2012/19/EU
